Pilz PSS Series Installation Manual

Installation
4-2 Installation Manual: PSS 3056 Series
277 mm (10.91")
10 mm
(0.39")
No min.
distance from control
cabinet required
Distance from top
min. 130 mm (5.12")
Power section
min. 60 mm (2.36")
Cable duct max. (W x H):
100 x 50 mm (3.94" x 1.97")
201 mm
(7.91")
10 mm
(0.39")
RUN FS
PG
RUN ST
POWER
FS RUN
STOP
ST AUTO PG
SPS
RUN FS
PG
RUN ST
POWER
FS RUN
STOP
ST AUTO PG
SPS
F-Stack
24 V
0 V
PG
RS 232
I31 I29 I30 I28 I27 I26 I25 I24 I23 I21 I22 I20 I19 I18 I17 I16 I15 I13 I14 I12 I11 I10 I9 I8 I7 I5 I6 I4 I3 I2 I1 I0 0 V 0 V 0 V 0 V
O0 O2 O1 O3 O4 O5 O6 O7 O8 O10 O9 O11 O12 O13 O14 O15 O16+ O17+ O16- O17- O18+ O18- O19+ O19- O20+ O21+ O20- O21- O22+ O22- O23+ O23- 24 V 24 V 0 V 0 V 24 V 0 V 24 V 0 V
F-Stack
24 V
0 V
PG
RS 232
I31 I29 I30 I28 I27 I26 I25 I24 I23 I21 I22 I20 I19 I18 I17 I16 I15 I13 I14 I12 I11 I10 I9 I8 I7 I5 I6 I4 I3 I2 I1 I0 0 V 0 V 0 V 0 V
O0 O2 O1 O3 O4 O5 O6 O7 O8 O10 O9 O11 O12 O13 O14 O15 O16+ O17+ O16- O17- O18+ O18- O19+ O19- O20+ O21+ O20- O21- O22+ O22- O23+ O23- 24 V 24 V 0 V 0 V 24 V 0 V 24 V 0 V
Installing the system in a control cabinet
Earth
connection
Fig. 4-2: Installing the PSS system in a control cabinet, dimensions stated in mm (")
Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com

Pilz PSS Series Specifications

General

Category	Safety Equipment
Manufacturer	Pilz
Safety Standards	EN ISO 13849-1, IEC 61508, IEC 62061
Series	PSS
Safety Integrity Level	SIL 3
Communication Interfaces	Ethernet, PROFIBUS, PROFINET
Operating Voltage	24 V DC
Operating Temperature	0°C to +55°C (typical), others depending on model
Storage Temperature	-20°C to +70°C (typical), others depending on model
Protection Class	IP20
Application	Industrial safety applications
