Connecting the Inputs and Outputs
5-12 Installation Manual: PSS 3056 Series
Example: Single-channel, failsafe input device, with test pulse
Features:
The input device must be approved for failsafe applications.
Please read the instructions provided with the input device.
The test pulse must be allocated to the input via the configurator on the
programming device.
Testing will detect short circuits between lines L+ and L-, and also
between the pulsed outputs.
Only input devices with N/C contacts can be tested.
Cable runs:
- 200 m
- With 1 kOhm resistance parallel to input: max. 800 m
CAUTION!
Short circuits between the cable from the signal to the input device and the
cable from the input device to the input will not be detected.
