5-17Installation Manual: PSS 3056 Series
24 V DC
L+
L-
O0
O2
O1
O3
O4
O5
O6
O7
O8
O10
O9
O11
O12
O13
O14
O15
O16+
O17+
O16-
O17-
O18+
O18-
O19+
O19-
O20+
O21+
O20-
O21-
O22+
O22-
O23+
O23-
24 V
24 V
0 V
0 V
24 V
0 V
24 V
0 V
Configuration of the standard PSS 3056
Please ensure safety regulations and EMC guidelines are observed!
Test pulse outputs
or single-pole 2 A
outputs
Signals
for input
devices
• Each output is protected against short circuit, overload and
overtemperature. Outputs are designed for resistive and inductive loads.
Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com

Pilz PSS Series Specifications

General

Category	Safety Equipment
Manufacturer	Pilz
Safety Standards	EN ISO 13849-1, IEC 61508, IEC 62061
Series	PSS
Safety Integrity Level	SIL 3
Communication Interfaces	Ethernet, PROFIBUS, PROFINET
Operating Voltage	24 V DC
Operating Temperature	0°C to +55°C (typical), others depending on model
Storage Temperature	-20°C to +70°C (typical), others depending on model
Protection Class	IP20
Application	Industrial safety applications
