Connecting the Inputs and Outputs
5-8 Installation Manual: PSS 3056 Series
Example: Single-channel, failsafe input device, unchecked
Features:
• The input device must be approved for failsafe applications.
• Please read the instructions provided with the input device.
CAUTION!
The connection shown overleaf is only approved for non-safety
applications. The connection of safe input devices for safety-relevant
applications is described later in the chapter.
