5-9
PSS WIN-PRO Service Version: Getting Started
If the block is programmed in IL, a table will be inserted within the
program code, displaying the contents of the operands, etc. If the block
is programmed in LD or FBD, the table will be displayed in a separate
window. If the window is not displayed, select
PSS -> Dynamic Pro-
gram Display -> Details Dynamic Program Display
. The display is
constantly updated.
The block for which the program display is being run is highlighted in
the program structure through the
symbol.
An icon on the block’s status bar shows which type of dynamic pro-
gram display is being run on a block:
Dynamic program display across one segment
Dynamic program display across several segments
6. Define displayed segment (only when
Start dynamic program
display across one segment
has been selected in step 5)
With program display across one segment, you can define the
segment for which the program display is to be run by changing the
cursor position.
Click in the segment for which the program display is to be run.
7. Change display format
The values can be displayed in binary, decimal or hexadecimal.
Select PSS -> Dynamic Program Display -> Display ....
8.
Define loop
(only when
Start dynamic program display across one
segment
has been selected in step 5)
If loops are programmed within the block, it is possible to define the
loop cycle on which the display should occur. The set loop is displayed
in the status bar of the block window.
Select
PSS -> Dynamic Program Display -> Select Loop
.
