5-11
PSS WIN-PRO Service Version: Getting Started
Display variables
Alongside dynamic program display, variable display is another useful aid
when searching for programming errors. With variable display, the values of
any operands from one or more blocks are displayed. Absolute addresses
from the programmable safety system can also be displayed.
The operands to be displayed must be entered in a variable table. There
may be several variable tables within a project’s FS and ST project section.
The PSS has one variable table for the FS section and one for the ST
section.
Fig. 5-4: Variable display
