Pioneer DJM-900NXS2 Service Manual

46
DJM-900NXS2
1
2 3 4
A
B
C
D
E
F
1
2 3 4
6.2 ABOUT THE DEVICE
MAIN UCOM AM3352BZCZ100 IC1 MAIN AssyMain control
DDR3 SDRAM K4B1G1646G-BCK0 IC9 MAIN AssyRAM for MAIN UCOM (WORK)
FLASH DYW**** IC8 MAIN AssyROM for MAIN UCOM (Firmware in MAC Address)
DSP D810K013DZKB456 IC1001 MAIN AssyAudio DSP
DSP_SDRAM1 M12L2561616A-5TG2S-K IC1003 MAIN AssyRAM for DSP
DSP_SDRAM2 M12L2561616A-5TG2S-K IC1004 MAIN AssyRAM for DSP
SRC_DSP D810K013DZKB456 IC1501 MAIN AssyAudio DSP
USBC UCOM R5S72670P144FP IC2004 MAIN AssyUSBC control
FLASH DYW**** IC2003 MAIN AssyROM for USBC UCOM
LAN PHY LAN8720A-CP IC16 MAIN AssyPHY for Ether net LINK
PANEL UCOM DYW****
Note on DYW****
The "****" part of the part number changes each time the firmware is updated.
IC7001 PNLA AssyMain control. LED, OLED, KEY, VR control
X-PAD TOUCH
CONTROLLER
ATSAMD20E15A-MU IC4902 CDCB AssyContact position detection of a X-PAD
Two or more FLASH and SDRAM are mounted in this unit.
Please judge the device which you should diagnose in reference to this list.
Device Name Part No. Ref. No. AssyFunction

Pioneer DJM-900NXS2 Specifications

General

MIDI out	Yes
Phono inputs (RCA)	4
USB 2.0 ports quantity	3
Digital audio coaxial out	1
Sample rate	96 kHz
Frequency range	20 - 40000 Hz
Channels quantity	4 channels
Line Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.005 %
Power consumption (typical)	42 W
Type	Magvel Fader

Weight and Dimensions

Depth	414.2 mm
Width	333 mm
Height	107.9 mm
Weight	8000 g
