Pioneer DJM-900NXS2 Service Manual

7
DJM-900NXS2
5
6 7 8
5
6 7 8
A
B
C
D
E
F
3.3 PCB LOCATIONS
TRM1 TRM2 TRM3 TRM4
SW POWER
SUPPLY
X
USBP
ASSY
I
MTRM
ASSY
F
MAIN
ASSY
G
HPJM
ASSY
O
CRFD ASSY
W
PNLB ASSY
V
PNLA ASSY
P
CDCB ASSY
U
FAD1 ASSY
Q
FAD4 ASSY
T
FAD2 ASSY
R
FAD3 ASSY
S
ACSW
ASSY
Y
SEND
ASSY
L
USBC
ASSY
J
REGB ASSY
H
HPPW ASSY
M
HPJK ASSY
N
TRM4 ASSY
E
USBB ASSY
K
GRDM ASSY
Z
TRM3 ASSY
D
TRM1 ASSY
B
TRM2 ASSY
C
AINB ASSY
A
Mark No. Description Part No. Mark No. Description Part No.
LIST OF ASSEMBLIES
Bottom view

Pioneer DJM-900NXS2 Specifications

General

MIDI out	Yes
Phono inputs (RCA)	4
USB 2.0 ports quantity	3
Digital audio coaxial out	1
Sample rate	96 kHz
Frequency range	20 - 40000 Hz
Channels quantity	4 channels
Line Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.005 %
Power consumption (typical)	42 W
Type	Magvel Fader

Weight and Dimensions

Depth	414.2 mm
Width	333 mm
Height	107.9 mm
Weight	8000 g
