Item for Which User's
Setting is Available
Setting Value Part No.
Content to be
Stored
PEAK LIMITER
MASTER OUT
DIGITAL MASTER OUT
BOOTH OUT
MIC OUT TO MASTER
OFF, ON*
ATT. –12 dB, –9 dB, –6 dB, –3 dB, 0 dB*
MONO/STEREO MONO, STEREO*
LEVEL –19 dB*, –15 dB, –10 dB, –5 dB
SAMPLING RATE 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz*
PEAK LIMITER OFF, ON*
MONO/STEREO MONO, STEREO*
ATT. –12 dB, –9 dB, –6 dB, –3 dB, 0 dB*
MONO/STEREO MONO, STEREO*
PEAK LIMITER THRESHOLD LEVEL 0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 15 dB, OFF*
TALK OVER
MODE ADVANCED*, NORMAL
MIDI
CH 1* to 16
BUTTON TYPE TOGGLE*, TRIGGER
LEVEL –24 dB, –18 dB*, –12 dB, –6 dB
PEAK LIMITER THRESHOLD LEVEL 0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 15 dB, OFF*
OFF, ON*
MIC OUT TO BOOTH
MIC LOW CUT
1 to 3*OLED BRIGHTNESS
OFF*, ONPC UTILITY
OFF, ON*AUTO STANDBY
OFF, ON*LOCK
YES / NO*Factory Reset
LEVEL OFF, –18 dB, –15 dB, –12 dB, –9 dB, –6 dB,
–3 dB, 0 dB*
*: Setting upon purchase
IC8
(MAIN Assy)
UTILITY setting
This unit is provided with user settable items, as shown below.
Although no serious operational problems occur even if data for such user settable items are cleared during repair, it is
recommended that you take note of those settings before starting repair.
Use the Check Sheet, to which you can transcribe the settings.
(See "g Sheet for confirmation of the user setting" on next page.)
If the corresponding part or board Assy is replaced for repair, change the user resettable settings to those noted on the Check
Sheet before starting repair. If resetting is not possible, when returning the repaired product, be sure to tell the customer that
the Utility settings have been cleared and will have to be reset, as required.
To Next Page
