Section
lID (Setting
the
Unit
)
C )
Rear
side
Front
side
What's
what
®
LPF
(low-pass filter) switch
Switch the settings based
on
the
connected
speaker.
• When the Subwoofer is connected:
Select
ON. This eliminates high range
frequency and outputs low range fre-
quency.
• When the full range speaker
is
con-
nected:
Select
OFF.
OFF
outputs
the
entire fre-
quency range.
~
Setting gain properly
• Protective function included to prevent
malfunction of the unit and/or speakers
due to excessive output, improper
use
or
improper connection.
• When outputting high volume sound etc.,
this function cuts off the
output
for a few
seconds as a normal function, but output
is
restored when the volume of the head
unit is turned down.
• A cut
in
sound output may indicate impro-
per setting of the gain control.
To
ensure
continuous sound output with the head
unit at a high volume, set amplifier gain
control to a
level
appropriate
for
the preout
maximum output
level
of the head unit,
so
that volume can remain unchanged and to
control excess output.
• Despite correct volume and gain settings,
the unit sound still cuts out periodically.
In
such cases, please contact the nearest
authorized Pioneer Service Station.
Gain control
of
this
unit
GAIN
NORMAL
preoutlevel:2~~
(Standard: 500mV)
~
6.5~
O.2~
.-
-
-
'ff--
~
~,'ii
-
A
,.
~
A
.'.
0
I-
'--
--
To
adjust the switch, use a flathead screwdri-
ver if needed,
CD
Power
indicator
The
power indicator lights up to indicate
power
ON.
(g)
BASS
BOOST
(bass
boost level control)
switch
You
can select a bass boost
level
from 0 dB,
6 dB and
12
dB.
® GAIN (gain) control
If output remai
ns
low,
even
when the car
stereo volume
is
turned up, turn controls to
lower
level.
If distortion occurs when the car
stereo volume
is
turned up, turn these con-
trols to higher level.
•
For
use with
an
RCA
equipped car stereo
(standard output of
500
mV),
s~t
to the
NORMAL position.
For
use with
an
RCA
equipped Pioneer car stereo, with max,
output of 4 Vor more, adjust
level
to
match that of the car stereo output.
• If you hear too much noise when using
the speaker input terminals, turn the
gain control to higher level.
CI)
En
