2.9 UPPER LAYER SECTION (1)
2
14
16
15
14
13
13
1413
13
1
5
9
8
17
S4001
(CBIT_1)
S4004
(CBIT_0)
6
7
4
12
11
10
3
J201
J202
14
13
13
S4001
CBIT_1
S4004
CBIT_0
PDP-433P → →
PDP-433PU → →
PDP-433PE ← →
PDP-433PG ← →
Set the slide switches in accordance with applicable
model when replacing the MR INTERFACE Assy.
Note 1 : When there is not S4004, set only S4001.
Note 2 : When there are not S4001 and S4004, setting
is unnecessary.
Caution in the MR INTERFACE Assy Replacement
