6.4.2 GET Commands
Command Function
GAJ Outputting data for electronic-control-adjustment values and drive-system-adjustment values
GPW Outputting data relating to the white-balance adjustment for the panel
GS1 Outputting data such as version information, and data from the hour meter and pulse meter
Order Data Contents Size Remarks
1 Setting mode of electric power upper limit value 3 byte AB* ( *: 0 to 3)
2
Electric power upper limit value
(ABL)
(Reference data) 3 byte
3 (Offset data) 3 byte (Note 1)
4 Vsus adjustment value (Reference data) 3 byte
5 Vofs adjustment value (Reference data) 3 byte
6 V-SUS-B adjustment value (Reference data) 3 byte
7 V-SUS-G adjustment value (Reference data) 3 byte
8 Y-SUS-B adjustment value (Reference data) 3 byte
9 Y-SUS-G adjustment value (Reference data) 3 byte
Order Data Contents Size Remarks
1 Panel color temperature mode 3 byte PT* ( *: 0 to 3)
2
Gain of W/B adjustment value
Red
(Reference data) 3 byte
3 (Offset data) 3 byte (Note 1)
4
Gain of W/B adjustment value
Green
(Reference data) 3 byte
5 (Offset data) 3 byte (Note 1)
6
Gain of W/B adjustment value
Blue
(Reference data) 3 byte
7 (Offset data) 3 byte (Note 1)
8
Offset of W/B adjustment value
Red
(Reference data) 3 byte
9 (Offset data) 3 byte (Note 1)
10
Offset of W/B adjustment value
Green
(Reference data) 3 byte
11 (Offset data) 3 byte (Note 1)
12
Offset of W/B adjustment value
Blue
(Reference data) 3 byte
13 (Offset data) 3 byte (Note 1)
GAJ: Outputting data for electronic-control-adjustment values and drive-system-adjustment values
• Output the data according to the order and size of the table below.
GPW: Outputting data relating to the white-balance adjustment for the panel
• Output the data according to the order and size of the table below.
(Note 1) : If data are output when Reference mode is selected, the same data as the reference data are output as the offset data.
(Note 2) : A checksum of 2 bytes is added at the end, but this can be ignored.
(Note 1) : If data are output when Reference mode is selected, the same data as the reference data are output as the offset data.
(Note 2) : A checksum of 2 bytes is added at the end, but this can be ignored.
