PDP-433PU
32
1234
1234
C
D
F
A
B
E
2.14 PANEL CHASSIS (43) ASSY (AWU1067)
PANEL CHASSIS(43) ASSY parts List
Mark No. Description Part No.
NSP SCAN FUKUGO ASSY AWV1969 *
NSP ADDRESS FUKUGO ASSY AWV1928 *
NSP Address Module (IC1 - IC32) AXF1114
NSP FPC (J1,J2) ADY1079
NSP FPC (J3,J4) ADY1080
NSP 1..Chassis Assy (43) ANA1712
NSP 2..Chassis (43) ANA1668
NSP 2..Base Chassis (43) ANA1669
NSP 2..Scan Heatsink (43) ANH1610
NSP 2..Corner Angle A ANG2457
NSP 2..Corner Angle B ANG2458
2..Insulation Seet A AEC1923
2..Insulation Seet B AEC1924
NSP 2..Tube Cover AMR3262
2..Rear Coner Label AAX2862
2..Silicone Sheet 43 AEH1043
2..Adhesive Tape 43 AEH1044
2..Adhesive Tape B 43 AEH1054
2..Panel Silicone Sheet AEH1055
2..Silicone Sheet B43 AEH1056
Pin Grommet AEC1015
Scan Silicone Sheet AEH1058
NSP Plasma Panel Assy (43) AAV1239
Screw VBB30P100FNI
Protection Tape AEH1059
Mark
No. Description Part No.
NSP 1..SCAN FUKUGO ASSY AWV1969
2..SCAN (A) ASSY AWZ6724
2..SCAN (B) ASSY AWZ6725
2..X CONNECTOR (A) ASSYAWZ6726
2..X CONNECTOR (B) ASSYAWZ6727
2..BRIDGE A ASSY AWZ6728
2..BRIDGE B ASSY AWZ6729
2..BRIDGE C ASSY AWZ6730
2..BRIDGE D ASSY AWZ6731
NSP 1..ADDRESS FUKUGO ASSY AWV1928
NSP 2..ADR CONNECT A ASSY AWZ6678
NSP 2..ADR CONNECT B ASSY AWZ6679
NSP 2..ADR CONNECT C ASSY AWZ6680
NSP 2..ADR CONNECT D ASSY AWZ6681
2..ADR RESONANCE ASSYAWZ6751
To Next Page
