PDP Service Assy 433 (AWU1069)
Circuit Board Spacer
(AEC1872)
Circuit Board Spacer
(AEC1872)
Caution in Replacement of Chassis Block
Please order the PDP Service Assy 433 (AWU1069) when replacing the Chassis block.
PDP Service Assy 433 is all common use parts for business, consumer models and module.
It is supplied by installing the Circuit Board Spacer (AEC1872) and the Wire Saddle (AEC1904) as follows.
Therefore it is necessary to remove them in accordance with the models.
Confirm the character of the seal carved near the parts, and then remove them.
P: for Consumer models only
W: for Module only
PW : Common use for Consumer models and Module
∗ In case of this unit(433PU, 433PE or 433PG), remove the part that "W" is marked(one part).
(There is marking of "P" nearby.)
Wire Saddle
(AEC1904)
To Next Page
