PDP-433PU
76
1234
1234
C
D
F
A
B
E
GS1:
Outputting data such as version information, and data from the hour meter and pulse meter
• Output the data according to the order and size of the table below.
Order Data Contents Size Remarks
1 Display information 3 byte See below
2 Module microcomputer model number 4 byte 5691 or F691
3 Module microcomputer version 3 byte
4 Panel microcomputer version 3 byte
5 Panel /FLASH ROM version 3 byte
6 Hour meter (hour) 5 byte Unit: H (hour)
7 Pulse meter 7 byte Unit: 0.01G (10,000,000)
8 Main microcomputer model number 4 byte 5692 or F692
9 Main microcomputer version 3 byte
10 Wide microcomputer version 3 byte
11 Wide /FLASH ROM version 3 byte
Data Model
MX5 PDP-503MX (initial value)
MX4 PDP-433MX
MD5 Module 50 inches
MD4 Module 43 inches
HD5 PDP-503HD
HD4 PDP-433HD
Display Information
Note: A checksum of 2 bytes is added at the end, but this can be ignored.
