UPPER LAYER SECTION(2) parts List
(2) CONTRAST TABLE
PDP-433PU/KUC, PDP-433PE/WYVI6, PDP-433PE/WYVI6XK and PDP-433PG/TLDPKBR are constructed the
same except for the following:
Mark
No. Description Part No.
> 1 SW Power Supply Module AXY1059
2• • • • •
3 IF Earth Metal ANA1690
4• • • • •
> 5 L1 Ferrite Core ATX1032
> 6 CN1 AC Inlet with Filter AKP1223
7 J105 Wire PB ADX2826
8 J114 Earth Wire ADX2709
9 SP TERMINAL Assy AWZ6688
10 J101 13P Housing Wire ADX2768
11 J118 Wire P ADX2765
12 J103 13P Housing Wire ADX2766
13 J102 Wire PE ADX2738
14 Screw PMB30P060FNI
15 Screw AMZ30P060FZK
16 Screw BPZ30P080FZK
17 Solder Warning Label See Contrast table (2)
18 Screw BMZ30P060FZK
Mark
No. Description Part No.
Mark No. Symbol and Description PDP-433PU/KUC
PDP-433PE/
WYVI6
PDP-433PE/
WYVI6XK
PDP-433PG/
TLDPKBR
17 Solder Warning Label AAX2644 Not used Not used Not used
