C6206,C6210,C6215,C6219,C6227 CCSRCH181J50
C6229,C6236,C6240,C6244,C6246 CCSRCH181J50
C6255,C6260 CCSRCH181J50
C6208,C6209,C6217,C6218,C6226 CCSRCH331J50
C6230,C6238,C6239,C6245,C6250 CCSRCH331J50
C6257,C6258 CCSRCH331J50
C6204,C6207,C6214,C6216 CCSRCH390J50
C6224,C6225,C6234,C6237 CCSRCH390J50
C6248,C6249,C6254,C6256 CCSRCH390J50
C6211,C6221,C6228,C6241,C6247 CKSRYB105K6R3
C6261 CKSRYB105K6R3
RESISTORS
R6207,R6209,R6222,R6228,R6232 RAB4C221J
R6239 RAB4C221J
Other Resistors RS1/16S###J
OTHERS
CN6201 15P CONNECTOR AKP1218
K6202,K6212,K6219,K6225,K6231 AKX9002
K6239,K6244 TEST PIN AKX9002
X CONNECTOR (A) ASSY [AWZ6726]
RESISTORS
All Resistors RS1/16S###J
X CONNECTOR (B) ASSY [AWZ6727]
RESISTORS
All Resistors RS1/16S###J
BRIDGE A ASSY [AWZ6728]
SEMICONDUCTORS
D6421 D1FL20U(S)
CAPACITORS
C6421 (0.1uF/100V) ACG1098
OTHERS
CN6421 PH CONNECTOR B4B-PH-SM3
BRIDGE B ASSY [AWZ6729]
SEMICONDUCTORS
D6431 D1FL20U(S)
CAPACITORS
C6431 (0.1uF/100V) ACG1098
OTHERS
CN6431 PH CONNECTOR B4B-PH-SM3
BRIDGE C ASSY [AWZ6730]
SEMICONDUCTORS
D6441 D1FL20U(S)
CAPACITORS
C6441 (0.1uF/100V) ACG1098
OTHERS
CN6441 PH CONNECTOR B4B-PH-SM3
Mark No. Description Part No.
BRIDGE D ASSY [AWZ6731]
SEMICONDUCTORS
D6451 D1FL20U(S)
CAPACITORS
C6451 (0.1uF/100V) ACG1098
OTHERS
CN6451 B4B-PH-SM3
ADR CONNECT A ASSY [AWZ6678]
SEMICONDUCTORS
IC6501 TC74VHC541FT
Q6502 2SC2712
Q6503 2SK209
D6501 DA227
COILS AND FILTERS
L6501,L6502 (22uH/0.11A) ATH1081
CAPACITORS
C6504,C6513-C6520 ACG1105
C6528 (330pF/100V) ACG1105
C6531,C6533,C6534 (47uF/6.3V) ACH1341
C6536-C6538 CCSRCH121J50
C6507-C6510,C6522-C6525,C6532 CKSRYF104Z16
C6535 CKSRYF104Z16
RESISTORS
R6519-R6522,R6526,R6528 RAB4C100J
R6530,R6531,R6534-R6537,R6541 RAB4C100J
R6543,R6545,R6547 RAB4C100J
R6516 RAB4C473J
Other Resistors RS1/16S###J
OTHERS
CN6501 55P CONNECTOR AKM1202
ADR CONNECT B ASSY [AWZ6679]
SEMICONDUCTORS
IC6601 TC74VHC541FT
Q6602 2SC2712
Q6603 2SK209
D6601 DA227
COILS AND FILTERS
L6601,L6602 (22uH/0.11A) ATH1081
CAPACITORS
C6604,C6613-C6620 ACG1105
C6628 (330pF/100V) ACG1105
C6631,C6633,C6634 (47uF/6.3V) ACH1341
C6636-C6638 CCSRCH121J50
C6607-C6610,C6622-C6625,C6632 CKSRYF104Z16
C6635 CKSRYF104Z16
RESISTORS
R6619-R6622,R6626,R6628 RAB4C100J
R6630,R6631,R6634-R6637,R6641 RAB4C100J
R6643,R6645,R6647 RAB4C100J
R6616 RAB4C473J
Other Resistors RS1/16S###J
