PDP-433PU
53
5 678
56
7
8
C
D
F
A
B
E
Q3122,Q3128 FS7VS-14A
Q3102 HN1B04FU
D3119 1SS184
D3108,D3124,D3125,D3133 1SS355
D3126,D3131,D3200,D3203,D3205 D1FL40
D3208,D3212-D3215 D1FL40
D3101,D3102,D3117,D3202,D3207 EC11FS4
D3210,D3211 EC11FS4
D3216,D3217 RB751V-40
D3120,D3127-D3129,D3135,D3136 UDZ15B
COILS AND FILTERS
L3206,L3207 ATH1112
RADIAL LEAD INDUCTOR
L3201,L3204 CHOKE COIL ATH1113
L3202,L3205,L3210,L3211 ATH1118
CHOKE COIL
L3101 LFEA100J
L3107,L3108 LFEA101J
CAPACITORS
C3205,C3206,C3212,C3213 ACE1160
C3225,C3226 (1.5uF) ACE1160
C3139,C3143 (0.1uF/630V) ACG1092
C3223,C3224 (100pF/630V) ACG1104
C3132 (47uF/350V) ACH1346
C3200-C3202,C3207-C3209 ACH1352
(330uF/280V)
C3112 CEHAT101M16
C3102,C3107,C3115,C3204,C3211 CEHAT101M25
C3101 CEHAT221M25
C3104,C3106 CEHAT470M16
C3135 CEHAT470M25
C3154,C3163 CKSRYB332K50
C3137,C3138 CKSRYB473K25
C3103,C3105,C3108,C3109,C3111 CKSRYF104Z50
C3113,C3114,C3117,C3130,C3140 CKSRYF104Z50
RESISTORS
R3183,R3184,R3187 (15ohm) ACN1156
R3113,R3114,R3121,R3122,R3126 RAB4C100J
R3132,R3140,R3141 RAB4C100J
R3212,R3217,R3230,R3234,R3237 RS1/10S184J
R3240,R3242,R3245 RS1/10S184J
R3211,R3213,R3214,R3218 RS1/16S2000F
R3134,R3163 RS1/2S100J
R3103 RS1/2S102J
R3109 RS1/2S2R2J
R3102 RS1/2S561J
R3215,R3216 RS1MMF101J
R3228,R3229 RS1MMF122J
R3178,R3179 RS3LMF181J
VR3200,VR3204 (1kohm) ACP1089
Other Resistors RS1/16S###J
OTHERS
K3203,K3213 TEST PIN AKX9002
KN3105-KN3114 GROUND PLATE ANK-142
CN3101 13P PLUG KM250MA13
[X DD CON BLOCK]
SEMICONDUCTORS
IC3712 AN1431M
Mark No. Description Part No.
IC3701 MIP161
IC3702-IC3704 TLP181(GR)
Q3701 2SC2712
Q3800 HN1A01FU
D3710,D3711 1SS355
D3705,D3706 D1FL20U(S)
D3702 EC8FS6
D3708,D3709,D3713 RD110P
D3703 UDZ18B
D3707 UDZS5.6B
COILS AND FILTERS
L3701 RADIAL LEAD INDUCTOR ATH1110
T3701 VRN TRANSFORMER ATK1153
CAPACITORS
C3701 (22uF/315V) ACH1345
C3717 (47uF/350V) ACH1346
C3704 CEHAT101M16
C3706,C3711,C3714 CEHAT101M25
C3712 CEHAT331M16
C3705 CKSQYF104Z50
C3703,C3707,C3708,C3710 CKSRYB104K16
C3715,C3716 CKSRYB104K16
RESISTORS
R3732 RS1/16S1001F
R3806 RS1/16S1802F
R3701-R3704,R3706-R3717 RS1/16S1803F
R3805 RS1/16S2702F
R3731 RS1/16S3900F
R3802 RS1/16S5601F
R3738,R3739 RS1/2S102J
R3800,R3801 RS1/2S823J
VR3701 (1kohm) ACP1089
Other Resistors RS1/16S###J
Y DRIVE ASSY [AWZ6749]
[Y DRIVE LOGIC BLOCK]
SEMICONDUCTORS
IC2006 PE1013B
IC2007 TC74ACT540FT
IC2001,IC2003-IC2005 TC74ACT541FT
IC2101 TLP181(GR)
COILS AND FILTERS
L2001 LFEA100J
CAPACITORS
C2101 CEHAT100M50
C2003 CEHAT470M16
C2001,C2004,C2005,C2007,C2008 CKSRYF104Z50
C2010,C2102,C2104,C2122 CKSRYF104Z50
RESISTORS
R2015-R2018 RAB4C0R0J
R2001,R2002,R2005,R2011 RAB4C470J
R2037,R2038 RAB4C470J
R2035,R2036,R2039,R2040 RAB4C472J
Other Resistors RS1/16S###J
OTHERS
CN2001 50P CONNECTOR AKM1201
Mark No. Description Part No.
