Pioneer PDP-433PU User Manual

PDP-433PU
9
5 678
56
7
8
C
D
F
A
B
E
PACKING parts List
(2) CONTRAST TABLE
PDP-433PU/KUC, PDP-433PE/WYVI6, PDP-433PE/WYVI6XK and PDP-433PG/TLDPKBR are constructed the
same except for the following:
Mark
No. Description Part No.
1Packing Case(43) See Contrast table (2)
2 Carton(43) AHD3100
3Pad(43U) AHA2282
4 Mirror Mat AHG1284
5 SP Caution Sheet ARM1218
NSP 6 Warranty Card See Contrast table (2)
7Pad(43L) AHA2283
8• • • • •
9Power Cord Case See Contrast table (2)
10 • • • • •
11 Vinyl Bag AHG1310
12 • • • • •
13 Wiping Cloth AED1208
14 Binder Assy AEC1908
(Speed Clampx3, Bead Bandx3)
> 15 Power Cord See Contrast table (2)
> 16 Power Cord See Contrast table (2)
> 17 Power Cord See Contrast table (2)
18 Caution Sheet See Contrast table (2)
19 Ferrite Core See Contrast table (2)
20 Label (Blue 16) AAX2787
21 Label (Green 16) AAX2956
22 MIC Label See Contrast table (2)
23 SP Spacer AEC1925
Mark
No. Description Part No.
Mark No. Symbol and Description PDP-433PU/KUC
PDP-433PE/
WYVI6
PDP-433PE/
WYVI6XK
PDP-433PG/
TLDPKBR
1Packing Case(43) AHD3115 AHD3114 AHD3138 AHD3116
NSP 6 Warranty Card ARY1112 ARY1114 ARY1114 Not used
9Power Cord Case AHC1037 AHC1037 AHC1039 AHC1037
> 15 Power Cord ADG1208 Not used Not used Not used
> 16 Power Cord Not used ADG1173 ADG1173 Not used
> 17 Power Cord Not used ADG1193 ADG1193 Not used
18 Caution Sheet Not used ARM1213 ARM1213 ARM1213
19 Ferrite Core Not used ATX1039 ATX1039 ATX1039
22 MIC Label Not used Not used Not used AAX2951
