Pioneer PDP-434PU - Scan and Connector Assembly Removal; Multi Base Section Removal

PDP-434PU
71
5 678
56
7
8
C
D
F
A
B
E
1
Remove the 8 screws (M screws).
2
Remove the 2 pin connectors.
3
Remove the 43 SCAN A and B Assemblies.
4
Remove the 6 screws (M screws).
5
Remove the X CONNECTOR A and B Assemblies.
43 SCAN B Assy
PANEL IF Assy
43 SCAN A, B,
X CONNECTOR A and B Assemblies
3
1
Remove the 4 screws (M screws).
2
Remove the some connectors.
3
Remove the multi base section.
• PCB Location for multi base section
Multi base section
4
1
1
2
3
3
1
1
1
×4
2
4
4
5
4
4
4
4
HD SP TERMINAL Assy
HD AUDIO AMP Assy
43 SCAN A Assy
X CONNECTOR A
Assy
43 X DRIVE
Assy
43 Y DRIVE
Assy
X CONNECTOR B
Assy
5
1
1
2
1
1
3
