Useful Remote Control Features
14
English
VCR control buttons
When the Mode switch is set to VCR, VCRs connected to the
display can be operated with the remote control unit.
• Press the input selector button INPUT 1 to INPUT 7 that
matches the input terminal number to which the VCR is
connected, then the VCR can be operated using 1 to 8.
• VCRs made by other manufacturers can also be operated
using the remote control unit if the remote control signals of
the devices have been preset. See page 83.
1. CH +/–
Selects the channel on the VCR.
2. (PLAY)
Selects playback.
3. (REW)
Rewinds the tape and allows picture search.
4. SOURCE
Turns the power of the VCR on and off.
5. (PAUSE/STILL)
Pauses playback and displays still pictures.
6. (FF)
Rapidly advances the tape and allows picture search.
7. (REC)
Starts recording.
8. (STOP)
Stops tape transport.
1
4
3
7
6
85
2
Mode switch
(with “VCR”
selected)
To Next Page
