PDP-502MX, PDP-502MXE
13
1 Frame Shield H ANK1609
2 Frame H ANG2343
3 Frame V ANG2344
4 Frame Shield V ANK1610
5 Corner Holder ANG2347
6 Ferrite Core (L1) ATX1037
7 Sub Frame R ANG2334
8 Sub Frame L ANG2333
9 Bush C AEC1740
10 Wire Saddle AEC1745
11 AC Inlet with Filter (CN1)
See contrast table (2)
12 Shield Gasket B ANK1612
13 Shield Gasket D ANK1614
14 Shield Gasket C ANK1613
15 Terminal Panel
See contrast table (2)
16 Shield Gasket E ANK1634
17 ……………………………
NSP 18 IR Holder ANG2346
19 Edging Saddle AEC1737
20 Nylon Rivet AEC1671
21 Screw AMZ30P080FCU
22 Screw AMZ30P060FMC
23 Screw BMZ30P060FCU
24 Hexagon Screw BBA1051
25 Ferrite Core Holder AEC1818
26 FPC Cushion AEB1341
27 ……………………………
28 IR RECEIVER ASSY AWZ6399
29 Power Switch (S1) BSM1006
30 CONTROL ASSY AWZ6414
NSP 31 Control Shield Case ANK1626
NSP 32 Control Shield Cover ANK1627
NSP 33 Control Shield Plate ANG2380
34 ……………………………
35 SP TERMINAL ASSY AWZ6415
36 PCB Support AEC1270
37 Spacer AEC1847
38 Screw AMZ30P100FZK
NSP 39 Drive Voltage Label ARW1077
40 Screw BPZ30P080FZK
41 Nut ABN1033
42 Screw PMB40P080FMC
43 Ferrite Core (L2) ATX1031
44 Binder AEC1851
11 AC Inlet with Filter (CN1) AKP1202 AKP1193
15 Terminal Panel ANG2341 ANG2353
(2) CONTRAST TABLE
PDP-502MX/LUCBW and PDP-502MXE/YVLDK are constructed the same except for the following:
Mark
PDP-502MX PDP-502MXE
LUCBW YVLDK
Part No.
Remarks
Symbol and DescriptionNo.
Mark No. Description Part No.
(1) EXTERIOR (2/3) SECTION PARTS LIST
Mark No. Description Part No.
To Next Page
