PDP-502MX, PDP-502MXE
42
NSP ANALOG VIDEO ASSY AWV1769 AWV1790
VIDEO ASSY AWZ6441 AWZ6448
INPUT ASSY AWZ6394 AWZ6394
IR RECEIVER ASSY AWZ6399 AWZ6399
FAN CABLE B ASSY AWZ6404 AWZ6404
DIGITAL VIDEO ASSY AWV1815 AWV1815
X DRIVE ASSY AWV1817 AWV1817
Y DRIVE ASSY AWV1818 AWV1818
CABLE ASSY AWV1816 AWV1816
NSP U-COM ASSY AWV1774 AWV1792
UCOM ASSY AWZ6395 AWZ6473
SIDE SW ASSY AWZ6398 AWZ6398
SENSOR A ASSY AWZ6400 AWZ6400
FAN CABLE A ASSY AWZ6403 AWZ6403
AUDIO ASSY AWZ6413 AWZ6413
CONTROL ASSY AWZ6414 AWZ6414
SP TERMINAL ASSY AWZ6415 AWZ6415
POWER SUPPLY ASSY AWV1775 AWV1775
MAIN POWER ASSY AWZ6405 AWZ6405
RCC CONTROL A ASSY AWZ6406 AWZ6406
RCC CONTROL B ASSY AWZ6407 AWZ6407
RCC CONTROL C ASSY AWZ6408 AWZ6408
OTL CONTROL A ASSY AWZ6409 AWZ6409
OTL CONTROL B ASSY AWZ6410 AWZ6410
OTL CONTROL C ASSY AWZ6411 AWZ6411
VF DD CONVERTER ASSY AWZ6412 AWZ6412
X CABLE U ASSY AWZ6396 AWZ6396
X CABLE D ASSY AWZ6397 AWZ6397
YC SEPA. ASSY AWV1776 Not used
PCB PARTS LIST
NOTES : ÷ Parts marked by “ NSP ” are generally unavailable because they are not in our Master Spare Parts List.
÷ The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
÷ When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex. 1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by
J = 5%, and K = 10%).
560 Ω = 56 × 10
1
= 561 ................................................... RD1/4PU 5 6 1 J
47k Ω = 47 × 10
3
= 473 .................................................. RD1/4PU 4 7 3 J
0.5 Ω = R50 ...................................................................... RN2H Â 5 0 K
1 Ω = 1R0 ......................................................................... RS1P 1 Â 0 K
Ex. 2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω = 562 × 10
1
= 5621 ........................................... RN1/4PC 5 6 2 1 F
LIST OF WHOLE PCB ASSEMBLIES
Mark
Remarks
Symbol and Description
Part No.
PDP-502MX
LUCBW
PDP-502MXE
YVLDK
4. PCB DIAGRAM
For PCB DIAGRAM, refer to the service manual ARP3044 for PDP-502MX/LUCBW.
