PDP-502MX, PDP-502MXE
15
NSP 1 Panel Shield S ANK1633
NSP 2 Panel Shield L ANK1632
NSP 3 Frame Assy ANA1626
4 ……………………………
5 ……………………………
6 ……………………………
7 ……………………………
8 ……………………………
9 PCB Spacer AMR3155
10 ……………………………
11 CABLE ASSY AWV1816
12 Y DRIVE ASSY AWV1818
13 X CABLE D ASSY AWZ6397
14 X DRIVE ASSY AWV1817
15 X CABLE U ASSY AWZ6396
16 DIGITAL VIDEO ASSY AWV1815
17 UCOM ASSY
See contrast table (2)
18 SCAN MODULE (IC41–IC44) MC-16343
NSP 19 Tube Cover AMR3036
NSP 20 Push Rivet AEC1748
21 Insulator AEZ1013
22 PCB Mold AMR2115
23 Locking Spacer AEC1794
24 Screw Grommet AEC-905
25 Insulating Sheet AMR3156
NSP 26 Scan Heat Sink ANH1558
27 Silicone Sheet AEH1028
NSP 28 Circuit Board Spacer AEC1744
29 Earth Plate (KN1, KN2) ANK-142
30 Locking Spacer AEC1796
31 Plastic Rivet AMR1066
32 AUDIO ASSY AWZ6413
NSP 33 PCB Spacer AEC1446
NSP 34 Blind Sheet S AMR3202
NSP 35 Blind Sheet L AMR3203
NSP 36 Hot Plate A ANG2338
NSP 37 Hot Plate B ANG2339
38 Circuit Board Spacer AEC1795
39 Screw ABZ30P160FCU
40 Screw INC30P100FZK
41 Screw IBZ30P250FCU
42 Plasma Panel Assy AAV1236
44 Screw ABZ30P060FCU
43 Screw ABZ30P080FCU
44 Hot Plate Barrier A AMR3210
45 Hot Plate Barrier B AMR3211
17 UCOM ASSY AWZ6395 AWZ6473
(2) CONTRAST TABLE
PDP-502MX/LUCBW and PDP-502MXE/YVLDK are constructed the same except for the following:
Mark
PDP-502MX PDP-502MXE
LUCBW YVLDK
Part No.
Remarks
Symbol and DescriptionNo.
Mark No. Description Part No.
(1) EXTERIOR (3/3) SECTION PARTS LIST
Mark No. Description Part No.
To Next Page
