Pioneer PDP-502MX Service Manual

PDP-502MX, PDP-502MXE
17
1 SIDE SWITCH ASSY AWZ6398
2 LED Lens AAK2695
3 Control Name Plate AAK2757
4 Control Shield ANK1606
5 Control Button AAC1540
6 Lens AAK2741
NSP 7 Panel Holder Assy ANG2386
8 Screw BPZ30P080FZK
9 Panel Shield H ANK1603
10 Panel Cushion H AED1189
11 Front Cushion H AED1191
12 Protect Panel Assy AMR3163
13 Front Cushion V AED1192
14 Corner Cushion AEB1360
15 Front Case See contrast table (2)
16 Panel Shield V ANK1604
NSP 17 Panel Holder V ANG2337
18 Panel Cushion V AED1190
19 Corner Gasket ANK1635
NSP 20 Panel Shield VM ANK1605
21 Pioneer Seal See contrast table (2)
22 Screw BBZ30P080FMC
23 Shield ANK1640
Mark No. Description Part No.
(1) FRONT CASE SECTION PARTS LIST
15 Front Case AMB2649 AMB2672
21 Pioneer Seal ARW1091 ARW1092
(2) CONTRAST TABLE
PDP-502MX/LUCBW and PDP-502MXE/YVLDK are constructed the same except for the following:
Mark
PDP-502MX PDP-502MXE
LUCBW YVLDK
Part No.
Remarks
Symbol and DescriptionNo.
