Pioneer PDP-502MX Service Manual

PDP-502MX, PDP-502MXE
48
Mark No. Description Part No.
Mark No. Description Part No.
R1817 RS1/10S2201F
R1409 RS1/10S2202F
R3403 RS1/10S2401F
R2486 RS1/10S3001F
R310, R321, R511, R542 RS1/10S3301F
R2086 RS1/10S3302F
R1811, R1815, R1820 RS1/10S3601F
R3401 RS1/10S3900F
R1818 RS1/10S3901F
R1812 –R1814, R1816, R1819 RS1/10S4701F
R1821, R1822, R307, R318, R508 RS1/10S4701F
R520 RS1/10S4701F
R1402 RS1/10S4702F
R2085 RS1/10S4703F
R309, R510 RS1/10S5601F
R320, R3405, R3408, R544 RS1/10S6201F
R1848 RS1/10S6801F
R2949, R2950 RS1/10S8200F
R2148, R2150, R2163, R2168, R2710 RS1/16S0R0J
R2717, R2725, R2913, R2914 RS1/16S0R0J
R2919 –R2927, R2936 –R2941, R3423 RS1/16S0R0J
R2709, R2713 –R2716, R2928 –R2930 RS1/16S100J
R2932 RS1/16S100J
R2033, R2041 –R2045, R2089 –R2091 RS1/16S101J
R2095, R2096, R2099 –R2109 RS1/16S101J
R2111 –R2113, R2118 –R2122, R2127 RS1/16S101J
R2237 –R2239, R2241 –R2252 RS1/16S101J
R2254 –R2261, R2273 –R2281, R2446 RS1/16S101J
R2448, R2450, R2494 –R2496, R2915 RS1/16S101J
R2706, R2740 RS1/16S102J
R2087, R2088, R2139 –R2141 RS1/16S103J
R2159, R2160, R2164 –R2167, R2170 RS1/16S103J
R2236, R2253, R2293 –R2298, R2332 RS1/16S103J
R2339 –R2342, R2348, R2349, R2447 RS1/16S103J
R2449, R2451, R3131, R3139 –R3141 RS1/16S103J
R2488, R2490, R2492 RS1/16S152J
R2744 RS1/16S2201D
R2701 –R2703, R2705, R2720, R2723 RS1/16S220J
R2742 RS1/16S220J
R2162 RS1/16S221J
R2743 RS1/16S2701D
R2489, R2491, R2493 RS1/16S302J
R2429, R2430, R2433, R2434 RS1/16S331J
R2741, R3418, R3424 RS1/16S332J
R2931, R2933, R2934 RS1/16S470J
R2918, R3130 RS1/16S472J
R2724 RS1/16S473J
R2497 RS3LMF1R5J
R3420, R3421 RS3LMF4R7J
R3422 RS3LMFR47J
Other Resistors RS1/10S J
OTHERS
CN2901, CN2902 30P CONNECTER 20143-030E-01
652 PIN JACK(2P) AKB1099
CN3408 TAB 1P AKM1177
CN651 JACK AKN1069
CN501, CN502 15PD-SUB SOCKET AKP1195
K1404, K1701 –K1703, K2004, K2005 AKX9002
K2012 –K2033, K2201 –K2213 AKX9002
K2404 –K2419, K2701 –K2716 AKX9002
K2901 –K2906 AKX9002
X2001 (16.0 MHz) ASS1145
CN2202 CONNECTOR B10B-PH-SM3
CN2203 CONNECTOR B11B-PH-SM3
CN2001, CN3401 CONNECTOR B12B-PH-SM3
CN503 CONNECTOR B13B-PH-SM3
CN2903, CN302 CONNECTOR B6B-PH-SM3
CN2002 CONNECTOR B7B-PH-SM3
CN304, CN3404 CONNECTOR B8B-PH-SM3
CN3406, CN3407 CONNECTOR B9B-PH-SM3
3406, 3407 SCREW BMZ30P060FCU
INPUT ASSY
SWITCHES AND RELAYS
S3501 ASH1029
RESISTORS
Other Resistors RS1/10S J
OTHERS
CN3503 CONNECTOR AKX1050
IR RECEIVER ASSY
SEMICONDUCTORS
IC3601 SBX8035–H
Q3601 2SC2712
D3601 1SS352
CAPACITORS
C3604 CEV470M6R3
C3603 CKSQYB472K50
C3601 CKSRYB103K50
C3602 CKSRYF104Z16
RESISTORS
R3602 RS1/16S101J
R3603, R3604 RS1/16S223J
R3601 RS1/16S472J
OTHERS
CN3601 3P PH CONNECTOR B3B–PH–SM3
