Pioneer PDP-502MX Service Manual

PDP-502MX, PDP-502MXE
68
Item Default Setting Remarks
Power(STAND-BY/ON) STANDBY
Input function INPUT1 (502MX), INPUT3 (502MXE)
Displaying size NATURAL WIDE (On video signal input) For each input function
(PC 1) ORIGINAL (including TYPE)
(On PC signal input) For INPUT 3, 4 ∩ each signal mode
(PC 2) 4: 3NORMAL (including TYPE)
The priority order is 1 = 2 = 3
(PC 3) FULL (including TYPE)
V. POSITION 0 (On video signal input) For each input function
0 (On "mode0F-3" input) For each INPUT 3, 4
KEYLOCK UNLOCK Common for all input functions
VOLUME 0 Common for all input functions
MUTING OFF Common for all input functions
PICTURE Center value for all adjustment items For each input function ∩ each signal mode
SCREEN Center value for all adjustment items For each input function ∩ each signal mode
(VIDEO) OFF (On video signal input) Common for all input functions
POWER SAVE
(PC) OFF (On PC signal input) Common for INPUT 3, 4
COLOR SYSTEM AUTO For each INPUT 1, 2
3D Y/C MODE (502MX only) MOTION For only INPUT 1
SETTING/SIGNAL PC/RGB For each INPUT 3, 4
CLAMP MODE1 (On RGB signal input) For each INPUT 3, 4
HIGH CONTRAST OFF (On video signal input) Common for all input functions
ABL ON (On PC signal input) For each INPUT 3, 4
H. ENHANCE Center value (On PC signal input) For each INPUT 3, 4
V. ENHANCE Center value (On PC signal input) For each INPUT 3, 4
PICTURE Adjustment values for all adjustment items Memory cleared for PC
For each input function ∩ each signal mode
WHITE BALANCE Adjustment values for all adjustment items Memory cleared for PC
For each input function ∩ each signal mode
SCREEN Center value for all adjustment items For each input function ∩ each signal mode
R LEVEL 100
SIDE MASK G LEVEL 97 Common for all input functions
B LEVEL 100
COLOR MODE 1 Common for all input functions
MIRROR MODE OFF Common for all input functions
BRIGHT ENHANCE (VIDEO) OFF (On video signal input) Common for all input functions
(PC) OFF (On PC signal input) Common for INPUT 3,4
OSD ON Common for all input functions
BAUD RATE 4800BPS Common for all input functions
FAN CONTROL AUTO Common for all input functions
HOUR METER 0 Operation hour
INPUT1 63
INPUT2 63
SUB VOLUME Independent sound volume for each input function
INPUT3 63
INPUT4 63
FULL MASK OFF
COLOR DETECT (502MX only) EURO
MASK CONTROL ON
lNTE. MODE ON Integrator mode operable.
lD No. – – (Not given) Only commands with ID:** operable
Details of FINAL SETUP ( Factory default setting)
