Pioneer PDP-503PU - Under Layer Sections Parts

PDP-503PE, PDP-503PU
9
2.2 UNDER LAYER SECTION (1)
NSP 1 CLAMP A Assy AWZ6650
NSP 2 CLAMP B Assy AWZ6651
NSP 3 CLAMP C Assy AWZ6652
NSP 4 CLAMP D Assy AWZ6653
5 Panel Chassis (50) Assy AWU1037
[Refer to "2.14 PANEL CHASSIS (50) ASSY".]
•
UNDER LAYER SECTION (1) PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
6 Wire Saddle AEC1904
7 Circuit Board Spacer AEC1872
8 Circuit Board Spacer AEC1873
NSP 9 PCB Support AEC1253
10 Locking Card Spacer AEC1736
11 Screw ABA1301
12 V Cushion AED1205
6
11
1
10
10
11
2
4
10
11
3
6
777
6
6
6
Upper side
6
8
9
9
8
6
67
6
5
10
1112
7
5
Refer to
"2.14 PANEL CHASSIS ASSY
(AWU1037)".
