Pioneer PDP-503PU User Manual

PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
c
ORDER NO.
PDP-503PE
ARP3107
T – IZE JAN. 2002 Printed in Japan
PDP-503PU
PLASMA DISPLAY
For details, refer to "Important symbols for good services".
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
This Service Manual should be used together with the following manual(s).
Component System Service Manual Remaks
Plasma Display System PDP-503HDE
Media Receiver PDP-R03E
PDP-R03E : ARP3110
PDP-R03U : ARP3113
Plasma Display PDP-503PE
PDP-5030HD
PDP-R03U
PDP-503PU
ARP3107
ARP3108
This service manual
This product is component of system.
Model No. Order No. Remarks
PDP-503PE
PDP-503PU
ARP3108 SCHEMATIC DIAGRAM and PCB DIAGRAM
Type
Model
Power Requirement Remarks
PDP-503PE PDP-503PU
WYVI6 ? − AC220 - 240V
KUC − ? AC120V
