75
PDP-503PE, PDP-503PU
Command Function
GAJ Output data of an electronic VR adjustment value and a drive system adjustment value
GPW Output data to be related to white balance adjustment of the panel
GS1 Output data such as version information, hour meter and pulse meter
Order Data Contents Size Remarks
1 Setting mode of electric power upper limit value 3 byte AB* ( *: 0 to 3)
2
Electric power upper limit value
(ABL)
(Reference data) 3 byte
3 (Offset data) 3 byte (Note 1)
4 Vsus adjustment value (Reference data) 3 byte
5 Vofs adjustment value (Reference data) 3 byte
6 V-SUS-B adjustment value (Reference data) 3 byte
7 V-SUS-G adjustment value (Reference data) 3 byte
8 Y-SUS-B adjustment value (Reference data) 3 byte
9 Y-SUS-G adjustment value (Reference data) 3 byte
Order Data Contents Size Remarks
1 Panel color temperature mode 3 byte PT* ( *: 0 to 3)
2
Gain of W/B adjustment value
Red
(Reference data) 3 byte
3 (Offset data) 3 byte (Note 1)
4
Gain of W/B adjustment value
Green
(Reference data) 3 byte
5 (Offset data) 3 byte (Note 1)
6
Gain of W/B adjustment value
Blue
(Reference data) 3 byte
7 (Offset data) 3 byte (Note 1)
8
Offset of W/B adjustment value
Red
(Reference data) 3 byte
9 (Offset data) 3 byte (Note 1)
10
Offset of W/B adjustment value
Green
(Reference data) 3 byte
11 (Offset data) 3 byte (Note 1)
12
Offset of W/B adjustment value
Blue
(Reference data) 3 byte
13 (Offset data) 3 byte (Note 1)
6.4.2 GET Command
GAJ:
Output data of an electron VR adjustment value and a drive system adjustment value
• Output it according to transmission order and size of the table below.
GPW (Get Panel White balance): Output data to be related to white balance adjustment of panel
• Output it according to transmission order and size of the table below.
(Note 1) : When performed in reference mode selection, offset data outputs the same value as the reference data.
(Note 2) : Checksum of 2 bytes is added at the end, but ignore it.
(Note 1) : When performed in reference mode selection, offset data outputs the same value as the reference data.
(Note 2) : Checksum of 2 bytes is added at the end, but ignore it.
Command Description
