PDP-503PE, PDP-503PU
GS1:
Output data such as version information, hour meter and pulse meter
• Output it according to transmission order and size of the table below.
Order Data Contents Size Remarks
1 Display information 3 byte See below
2 Module microcomputer model number 4 byte 5691 or F691
3 Module microcomputer version 3 byte
4 Panel microcomputer version 3 byte
5 Panel /FLASH ROM version 3 byte
6 Hour meter (hour) 5 byte Unit: H (time)
7 Pulse meter 7 byte Unit: 0.01G (10,000,000)
8 Main microcomputer model number 4 byte 5692 or F692
9 Main microcomputer version 3 byte
10 Wide microcomputer version 3 byte
11 Wide /FLASH ROM version 3 byte
Data Model
MX5 PDP-503MX (initial value)
MX4 PDP-433MX
MD5 Module 50 inches
MD4 Module 43 inches
HD5 PDP-503HD
HD4 PDP-433HD
Display Information
(Note) : Checksum of 2 bytes is added at the end, but ignore it.
