PDP-503PE, PDP-503PU
8
1
2
3
3
9
15
13
14
PDP-503PE
Only
PDP-503PU
Only
11
2
4
8
7
16
11
17
11
5
11
6
1 Upper Carton See Contrast table (2)
2 Under Carton AHD3037
3 Pad AHA2280
4 Mirror Mat AHG1284
5 Caution Sheet ARM1201
NSP 6 Warranty Card See Contrast table (2)
7 Polyethylene Sheet AHG1302
8 Front Sheet AHB1241
9 Cord Case AHC1037
10 • • • • •
11 Vinyl Bag AHG1310
12 • • • • •
13 Wiping Cloth AED1197
14 Binder Assy AEC1908
(Speed Clamp × 3, Bead Band × 3)
15 Power Cord See Contrast table (2)
16 Power Cord See Contrast table (2)
17 Power Cord See Contrast table (2)
2.1 PACKING
(1) PACKING PARTS LIST
Mark No. Description Part No.
2. EXPLODED VIEWS AND PARTS LIST
NOTES:
•
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•
Screws adjacent to mark on the product are used for disassembly.
•
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
(2) CONTRAST TABLE
PDP-503PE/WYVI6 and PDP-503PU/KUC are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
PDP-503PE PDP-503PU
WYVI6 KUC
NSP
1
6
15
16
17
Upper Carton
Warranty Card
Power Cord
Power Cord
Power Cord
AHD3104
ARY1114
ADG1173
ADG1193
Not used
AHD3103
ARY1112
Not used
Not used
ADG1178
