PDP-503PE, PDP-503PU
13
1 DIGITAL VIDEO Assy AWV1903
2 V MID CLAMP Assy AWV1934
3 X DRIVE Assy AWV1901
NSP 4 X CONNECTOR (A) Assy AWZ6618
NSP 5 X CONNECTOR (B) Assy AWZ6619
6 ADR RESONANCE Assy AWZ6691
7 SUB ADDRESS A Assy AWZ6689
8 SUB ADDRESS B Assy AWZ6690
NSP 9 Scan Heat Sink ANH1594
10 Coil Silicone Sheet AEH1048
11 Circuit Board Spacer AEC1873
12 Screw ABZ30P060FMC
13 Screw VBB30P100FNI
14 Screw PMB30P060FNI
15 J201 Flexible Flat Cable ADD1194
•
UNDER LAYER SECTION (3) PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
16 J202 Flexible Flat Cable ADD1194
17 J209 Flexible Flat Cable ADD1191
18 J204 Flexible Flat Cable ADD1196
19 J210 Flexible Flat Cable ADD1190
20 J211 Flexible Flat Cable ADD1186
21 J212 Flexible Flat Cable ADD1188
NSP 22 Holder ANG2509
NSP 23 Drive Heatsink Assy ANH1598
24 Silicone Sheet AEH1039
25 Drive Silicone Sheet AEH1041
26 Niplocker BEC1136
27 Insulation Sheet AMR3263
28 Flat Clamp AEC1879
NSP 29 Metal Fittings ANG2464
To Next Page
