PDP-503PE, PDP-503PU
17
NSP 1 ADR CONNECT A Assy AWZ6626
NSP 2 ADR CONNECT B Assy AWZ6627
NSP 3 ADR CONNECT C Assy AWZ6628
NSP 4 ADR CONNECT D Assy AWZ6629
5 ADR RESONANCE Assy AWZ6691
NSP 6 BRIDGE A Assy AWZ6620
NSP 7 BRIDGE B Assy AWZ6621
NSP 8 BRIDGE C Assy AWZ6622
NSP 9 BRIDGE D Assy AWZ6623
10 SUB ADDRESS A Assy AWZ6689
11 SUB ADDRESS B Assy AWZ6690
NSP 12 SCAN (A) Assy AWZ6617
NSP 13 SCAN (B) Assy AWZ6616
14 Y DRIVE Assy AWZ6645
15 DIGITAL VIDEO Assy AWV1903
16 THERMAL SENSOR Assy AWZ6660
NSP 17 X CONNECTOR (A) Assy AWZ6618
NSP 18 X CONNECTOR (B) Assy AWZ6619
19 X DRIVE Assy AWV1901
20 V MID CLAMP Assy AWV1934
•
UNDER LAYER SECTION (5) PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
21 J121 5P Housing Wire ADX2759
22 Flat Clamp AEC1879
23 J120 5P Housing Wire ADX2761
24 J110 3P Housing Wire ADX2704
25 J108 8P Housing Wire ADX2701
26 J101 Wire F ADX2726
27 J102 Wire E ADX2694
28 J103 13P Housing Wire ADX2700
29 J116 4P Housing SP Wire ADX2756
30 J109 Wire G ADX2720
31 Binder AEC-093
32 J117 4P Housing SP Wire ADX2756
To Next Page
