51
PDP-503PE, PDP-503PU
Mark No. Description Part No. Mark No. Description Part No.
COILS
L2207 RADIAL LEAD INDUCTOR ATH1110
L2213,L2214 ATH1112
RADIAL LEAD INDUCTOR
L2206,L2211 CHOKE COIL ATH1117
L2208,L2212,L2215,L2216 ATH1118
CHOKE COIL
L2210 LFEA100J
L2203,L2205 LFEA101J
L2201,L2204 LFEA470J
CAPACITORS
C2228,C2230,C2231,C2250-C2252 ACE1160
(1.5µF)
C2209,C2210 (0.1µF/630V) ACG1092
C2233,C2248 (100pF/500V) ACG1100
C2211 (47µF/350V) ACH1346
C2216,C2217,C2219,C2234-C2236 ACH1348
(330µF/315V)
C2253-C2260 CCSRCH331J50
C2221,C2225,C2226,C2246 CEHAT101M16
C2204,C2227,C2237,C2240,C2247 CEHAT101M25
C2202 CEHAT221M25
C2232 CEHAT331M2A
C2218,C2224,C2229 CEHAT470M16
C2212,C2214 CEHAT470M25
C2201,C2203,C2205,C2208,C2213 CKSRYF104Z50
C2220,C2222,C2223,C2238,C2239 CKSRYF104Z50
C2241,C2242 CKSRYF104Z50
RESISTORS
R2235,R2273,R2291,R2305,R2315 RAB4C100J
R2317,R2342 RAB4C100J
R2253,R2256,R2270,R2283,R2332 RS1/10S184J
R2338,R2354,R2355 RS1/10S184J
R2358-R2361 RS1/16S3300F
R2263,R2264 RS1/2S100J
R2203 RS1/2S102J
R2209 RS1/2S2R2J
R2202 RS1/2S561J
R2278,R2303 RS1MMF101J
R2233,R2234 RS1MMF102J
R2274,R2275 RS1MMF221J
R2298,R2299 RS2MMF4R7J
R2277 RS3LMFR47J
R2276 RS3LMFR56J
VR2201-VR2204 (1kΩ) ACP1089
Other Resistors RS1/16S J
OTHERS
SPACER AEH1049
K2211,K2214-K2217 TEST PIN AKX9002
KN2201-KN2210 GROUND PLATE ANK-142
CN2201 15P PLUG KM250MA15
CN2202 3P PLUG KM250MA3
[Y DRIVE SCAN BLOCK]
SEMICONDUCTORS
IC2501,IC2502,IC2505,IC2510 HCPL-M611
IC2512-IC2514,IC2516,IC2525 HCPL-M611
IC2503,IC2504,IC2506 TC74ACT540FT
COILS
L2501-L2503 LFEA100J
CAPACITORS
C2506,C2527 CEHAT220M2D
C2502 CEHAT221M16
C2524,C2525 CEHAT470M16
C2501,C2503-C2505,C2507,C2508 CKSRYF104Z50
C2513,C2515-C2517,C2519,C2530 CKSRYF104Z50
RESISTORS
R2502,R2504 RAB4C101J
Other Resistors RS1/16S J
OTHERS
CN2501,CN2502 AKM1200
15P CONNECTOR
[Y DRIVE DD-CON BLOCK]
SEMICONDUCTORS
IC2715-IC2717 AN1431M
IC2709 HCNR201
IC2708,IC2710,IC2718 M5223AFP
IC2711 MIP0223SC
IC2701 MIP161
IC2704 MIP301
IC2702,IC2703,IC2705-IC2707 TLP181(GR)
IC2712-IC2714 TLP181(GR)
Q2701,Q2703 2SC2712
Q2704 HN1A01FU
D2712,D2717,D2718,D2732,D2734 1SS355
D2736,D2737 1SS355
D2704,D2706,D2707,D2715,D2726 D1FL20U(S)
D2728 D1FL20U(S)
D2702,D2714,D2727 D1FL40
D2711 D1FS4
D2725 EC8FS6
D2733 RD110P
D2724 U1ZB330
D2713 U1ZB36
D2740 UDZ12B
D2709,D2716 UDZ3.6B
D2729,D2731 UDZ33B
D2703,D2710 UDZ36B
D2720,D2730,D2739 UDZS5.6B
COIL
L2701 RADIAL LEAD INDUCTOR ATH1110
TRANSFORMERS
T 2702 ATK1150
T 2703 ATK1151
T 2701 ATK1152
