50
PDP-503PE, PDP-503PU
Mark No. Description Part No. Mark No. Description Part No.
R3215,R3216 RS1MMF101J
R3228,R3229 RS1MMF102J
R3202,R3203 RS1MMF563J
R3178,R3179 RS2MMF121J
VR3200-VR3203 (1kΩ) ACP1089
Other Resistors RS1/16S J
OTHERS
SPACER AEH1049
K3102-K3104 TEST PIN AKX9002
KN3105-KN3114 GROUND PLATE ANK-142
CN3101 13P PLUG KM250MA13
CN3102 3P PLUG KM250MA3
[X DD CON BLOCK]
SEMICONDUCTORS
IC3712 AN1431M
IC3701 MIP161
IC3702-IC3704 TLP181(GR)
Q3701 2SC2712
Q3800 HN1A01FU
D3710,D3711 1SS355
D3705,D3706 D1FL20U(S)
D3702 EC8FS6
D3708,D3709,D3713 RD110P
D3703 UDZ18B
D3707 UDZS5.6B
COIL
L3701 RADIAL LEAD INDUCTOR ATH1110
TRANSFORMER
T3701 ATK1153
CAPACITORS
C3701 (22µF/315V) ACH1345
C3717 (47µF/350V) ACH1346
C3704 CEHAT101M16
C3706,C3711,C3714 CEHAT101M25
C3712 CEHAT331M16
C3705 CKSQYF104Z50
C3703,C3707,C3708,C3710 CKSRYB104K16
C3715,C3716 CKSRYB104K16
RESISTORS
R3732 RS1/16S1001F
R3806 RS1/16S1802F
R3701-R3704,R3706-R3717 RS1/16S1803F
R3805 RS1/16S2702F
R3731 RS1/16S3900F
R3802 RS1/16S5601F
R3738,R3739 RS1/2S102J
R3800,R3801 RS1/2S823J
VR3701 (1kΩ) ACP1089
Other Resistors RS1/16S J
Y DRIVE ASSY
[Y DRIVE LOGIC BLOCK]
SEMICONDUCTORS
IC2006 PE1013B
IC2007 TC74ACT540FT
IC2001,IC2003-IC2005 TC74ACT541FT
Q2121 2SK2201
Q2101,Q2102 HN1C01FU
D2101 1SS355
COIL
L2001 LFEA100J
CAPACITORS
C2101 CEHAT100M50
C2103 CEHAT1R0M50
C2003 CEHAT470M16
C2001,C2004,C2005,C2007,C2008 CKSRYF104Z50
C2010,C2102,C2104,C2121 CKSRYF104Z50
RESISTORS
R2015-R2018 RAB4C0R0J
R2001,R2002,R2005,R2011 RAB4C470J
R2037,R2038 RAB4C470J
R2035,R2036,R2039,R2040 RAB4C472J
Other Resistors RS1/16S J
OTHERS
CN2001 50P CONNECTOR AKM1201
K2001-K2005,K2009,K2010,K2013 AKX9002
TEST PIN
K2021,K2027-K2029,K2037 AKX9002
TEST PIN
K2039-K2041,K2053 TEST PIN AKX9002
2101 SENSOR AXX1057
SCREW BMZ20P040FMC
NUT NB20FMC
[Y DRIVE SUS BLOCK]
SEMICONDUCTORS
IC2202,IC2208 HCPL-M611
IC2206,IC2214 STK795-460
IC2201 TC74ACT541FT
IC2203,IC2204,IC2210,IC2212 TND301S
IC2213,IC2216,IC2217 TND301S
IC2205,IC2209 UPC78L05T
Q2203-Q2205 2SJ522
Q2201 2SK2503
Q2215-Q2221,Q2226-Q2228 FQB34N20
Q2232,Q2233 FQB34N20
Q2210-Q2212 FS16VS-9
Q2209 HN1B04FU
D2225 1SS184
D2202,D2204 1SS226
D2211 1SS355
D2201,D2203,D2205,D2208,D2210 D1FL40
D2212,D2214-D2216,D2221-D2223 D1FL40
D2226-D2228,D2239,D2243 D1FL40
D2209 DF20L60
D2206,D2207 UDZ15B
