Pioneer PDP-503PU User Manual

49
PDP-503PE, PDP-503PU
Mark No. Description Part No. Mark No. Description Part No.
ADR RESONANCE ASSY
SEMICONDUCTORS
IC6704 (1A/50V) ICP-S1.0
IC6701-IC6703 TND301S
Q6704,Q6705,Q6712 2SB1132
Q6701-Q6703 2SD1664
Q6710,Q6711 FS30ASJ-2
Q6706-Q6709 FX20ASJ-2
D6701,D6703,D6704,D6706 1SS355
D6709,D6710,D6717,D6718 D1FL20U(S)
D6711-D6714 SPX-62S
D6702,D6705,D6716 UDZ15B
COIL
L6704 CHOKE COIL ATH1111
CAPACITORS
C6716,C6718 (1.00F) ACE1159
C6720,C6721 (0.01µF/100V) ACG1101
C6722 (0.0068F/100V) ACG1102
C6703-C6708 (56µF/80V) ACH1347
C6702,C6709 CEHV101M16
C6701 CEHV470M16
C6710,C6711,C6713 CKSRYF104Z16
RESISTORS
All Resistors RS1/16S J
OTHERS
CN6701 23P CONNECTOR AKP1221
CN6702 PH CONNECTOR B4B-PH-SM3
CN6703 PH CONNECTOR B5B-PH-SM3
X DRIVE ASSY
[X LOGIC BLOCK]
SEMICONDUCTORS
IC3003 PE1012A
IC3004 TC74ACT540FT
IC3001,IC3008 TC74ACT541FT
COIL
L3001 LFEA100J
CAPACITORS
C3005 CEHAT470M16
C3001,C3003,C3004,C3006 CKSRYF104Z50
RESISTORS
R3009-R3012 RAB4C0R0J
R3001,R3003,R3026,R3029 RAB4C470J
R3002,R3005,R3030,R3033 RAB4C472J
Other Resistors RS1/16S J
OTHERS
K3001,K3003,K3004,K3008,K3010 AKX9002
TEST PIN
K3012-K3015,K3017,K3018 AKX9002
TEST PIN
CN3001 30P CONNECTOR KF050HA30L
[X SUS BLOCK]
SEMICONDUCTORS
IC3102 HCPL-M611
IC3200,IC3201 STK795-460
IC3101 TC74ACT541FT
IC3103,IC3104,IC3106,IC3107 TND301S
IC3110,IC3113 TND301S
IC3109 UPC78L05T
Q3117 2SJ181L
Q3116,Q3119,Q3120 2SJ522
Q3101 2SK2503
Q3103-Q3107,Q3109-Q3115 FS16VS-9
Q3124-Q3127 FS16VS-9
Q3123 FS2AS-14A
Q3122,Q3128 FS7VS-14A
Q3102,Q3118 HN1B04FU
D3119 1SS184
D3108,D3124,D3125,D3130,D3133 1SS355
D3101,D3102,D3117,D3126,D3131 D1FL40
D3200,D3202,D3203,D3205 D1FL40
D3207,D3208,D3210-D3215 D1FL40
D3120,D3127-D3129,D3135,D3136 UDZ15B
COILS
L3206,L3207 ATH1112
RADIAL LEAD INDUCTOR
L3201,L3204 CHOKE COIL ATH1117
L3202,L3205,L3210,L3211 ATH1118
CHOKE COIL
L3101 LFEA100J
L3107,L3108 LFEA101J
L3103 LFEA470J
CAPACITORS
C3205,C3206,C3212,C3213 (1.5µF) ACE1160
C3225,C3226 (1.5µF) ACE1160
C3131,C3139,C3143 (0.1µF/630V) ACG1092
C3223,C3224 (100pF/500V) ACG1100
C3132 (47µF/350V) ACH1346
C3200-C3202,C3207-C3209 ACH1348
(330µF/315V)
C3214-C3221 CCSRCH331J50
C3112,C3133,C3203,C3210 CEHAT101M16
C3102,C3107,C3115,C3204,C3211 CEHAT101M25
C3101 CEHAT221M25
C3104,C3106,C3134,C3141 CEHAT470M16
C3135 CEHAT470M25
C3103,C3105,C3108,C3109,C3111 CKSRYF104Z50
C3113,C3114,C3117,C3130,C3140 CKSRYF104Z50
C3147 CKSRYF104Z50
RESISTORS
R3183,R3184,R3187 (15Ω) ACN1156
R3113,R3114,R3121,R3122,R3126 RAB4C100J
R3132,R3140,R3141 RAB4C100J
R3212,R3217,R3230,R3234,R3237 RS1/10S184J
R3240,R3242,R3245 RS1/10S184J
R3250-R3253 RS1/16S3300F
R3134,R3163 RS1/2S100J
R3103 RS1/2S102J
R3109 RS1/2S2R2J
R3102 RS1/2S561J
