48
PDP-503PE, PDP-503PU
Mark No. Description Part No. Mark No. Description Part No.
CLAMP D ASSY
SEMICONDUCTORS
D6491,D6492 D1FL20U(S)
CAPACITORS
C6491,C6492 (0.1µF/100V) ACG1098
OTHERS
CN6491 PH CONNECTOR B4B-PH-SM3
ADR CONNECT A ASSY
SEMICONDUCTORS
IC6501 TC74VHC541FT
Q6502 2SC2712
Q6503 2SK209
D6501 DA227
COILS
L6501,L6502 (22µH/0.11A) ATH1081
CAPACITORS
C6511-C6520 (330pF/100V) ACG1094
C6531,C6533,C6534 (47µF/6.3V) ACH1341
C6536-C6538 CCSRCH121J50
C6506-C6510,C6521-C6525,C6532 CKSRYF104Z16
C6535 CKSRYF104Z16
RESISTORS
R6518-R6522,R6524,R6526,R6528 RAB4C100J
R6530,R6531,R6533-R6537,R6539 RAB4C100J
R6541,R6543,R6545,R6547 RAB4C100J
R6516 RAB4C473J
Other Resistors RS1/16S J
OTHERS
CN6501 55P CONNECTOR AKM1202
ADR CONNECT B ASSY
SEMICONDUCTORS
IC6601 TC74VHC541FT
Q6602 2SC2712
Q6603 2SK209
D6601 DA227
COILS
L6601,L6602 (22µH/0.11A) ATH1081
CAPACITORS
C6611-C6620 (330pF/100V) ACG1094
C6631,C6633,C6634 (47µF/6.3V) ACH1341
C6636-C6638 CCSRCH121J50
C6606-C6610,C6621-C6625,C6632 CKSRYF104Z16
C6635 CKSRYF104Z16
RESISTORS
R6618-R6622,R6624,R6626,R6628 RAB4C100J
R6630,R6631,R6633-R6637,R6639 RAB4C100J
R6641,R6643,R6645,R6647 RAB4C100J
R6616 RAB4C473J
Other Resistors RS1/16S J
OTHERS
CN6601 55P CONNECTOR AKM1202
ADR CONNECT C ASSY
SEMICONDUCTORS
IC6801 TC74VHC541FT
Q6802 2SC2712
Q6803 2SK209
D6801 DA227
COILS
L6801,L6802 (22µH/0.11A) ATH1081
CAPACITORS
C6811-C6820 (330pF/100V) ACG1094
C6831,C6833,C6834 (47µF/6.3V) ACH1341
C6836-C6838 CCSRCH121J50
C6806-C6810,C6821-C6825,C6832 CKSRYF104Z16
C6835 CKSRYF104Z16
RESISTORS
R6818-R6822,R6824,R6826,R6828 RAB4C100J
R6830,R6831,R6833-R6837,R6839 RAB4C100J
R6841,R6843,R6845,R6847 RAB4C100J
R6816 RAB4C473J
Other Resistors RS1/16S J
OTHERS
CN6801 55P CONNECTOR AKM1202
ADR CONNECT D ASSY
SEMICONDUCTORS
IC6901 TC74VHC541FT
Q6902 2SC2712
Q6903 2SK209
D6901 DA227
COILS
L6901,L6902 (22µH/0.11A) ATH1081
CAPACITORS
C6911-C6920 (330pF/100V) ACG1094
C6931,C6933,C6934 (47µF/6.3V) ACH1341
C6936-C6938 CCSRCH121J50
C6906-C6910,C6921-C6925,C6932 CKSRYF104Z16
C6935 CKSRYF104Z16
RESISTORS
R6918-R6922,R6924,R6926,R6928 RAB4C100J
R6930,R6931,R6933-R6937,R6939 RAB4C100J
R6941,R6943,R6945,R6947 RAB4C100J
R6916 RAB4C473J
Other Resistors RS1/16S J
OTHERS
CN6901 55P CONNECTOR AKM1202
