47
PDP-503PE, PDP-503PU
Mark No. Description Part No. Mark No. Description Part No.
C6203,C6206,C6210,C6215,C6219 CCSRCH151J50
C6227,C6229,C6236,C6240,C6244 CCSRCH151J50
C6246,C6255,C6259,C6260 CCSRCH151J50
C6208,C6209,C6217,C6218,C6226 CCSRCH181J50
C6230,C6238,C6239,C6245,C6250 CCSRCH181J50
C6257,C6258 CCSRCH181J50
C6204,C6205,C6207,C6214,C6216 CCSRCH390J50
C6220,C6224,C6225,C6231 CCSRCH390J50
C6234,C6235,C6237,C6248,C6249 CCSRCH390J50
C6251,C6254,C6256,C6262-C6266 CCSRCH390J50
C6211,C6221,C6228,C6241,C6247 CKSRYF104Z16
C6261 CKSRYF104Z16
RESISTORS
R6207,R6209,R6222,R6228,R6232 RAB4C221J
R6239 RAB4C221J
Other Resistors RS1/16S J
OTHERS
CN6201 15P CONNECTOR AKP1218
K6202,K6212,K6219,K6225,K6231 AKX9002
TEST PIN
K6239,K6244 TEST PIN AKX9002
X CONNECTOR (A) ASSY
RESISTORS
All Resistors RS1/16S J
X CONNECTOR (B) ASSY
RESISTORS
All Resistors RS1/16S J
BRIDGE A ASSY
SEMICONDUCTORS
D6421,D6422 D1FL20U(S)
CAPACITORS
C6421,C6422 (0.1µF/100V) ACG1098
OTHERS
CN6421 PH CONNECTOR B4B-PH-SM3
BRIDGE B ASSY
SEMICONDUCTORS
D6431,D6432 D1FL20U(S)
CAPACITORS
C6431,C6432 (0.1µF/100V) ACG1098
OTHERS
CN6431 PH CONNECTOR B4B-PH-SM3
BRIDGE C ASSY
SEMICONDUCTORS
D6441,D6442 D1FL20U(S)
CAPACITORS
C6441,C6442 (0.1µF/100V) ACG1098
OTHERS
CN6441 PH CONNECTOR B4B-PH-SM3
BRIDGE D ASSY
SEMICONDUCTORS
D6451,D6452 D1FL20U(S)
CAPACITORS
C6451,C6452 (0.1µF/100V) ACG1098
OTHERS
CN6451 PH CONNECTOR B4B-PH-SM3
CLAMP A ASSY
SEMICONDUCTORS
D6461,D6462 D1FL20U(S)
CAPACITORS
C6461,C6462 (0.1µF/100V) ACG1098
OTHERS
CN6461 PH CONNECTOR B4B-PH-SM3
CLAMP B ASSY
SEMICONDUCTORS
D6471,D6472 D1FL20U(S)
CAPACITORS
C6471,C6472 (0.1µF/100V) ACG1098
OTHERS
CN6471 PH CONNECTOR B4B-PH-SM3
CLAMP C ASSY
SEMICONDUCTORS
D6481,D6482 D1FL20U(S)
CAPACITORS
C6481,C6482 (0.1µF/100V) ACG1098
OTHERS
CN6481 PH CONNECTOR B4B-PH-SM3
