Pioneer PDP-503PU User Manual

54
PDP-503PE, PDP-503PU
Mark No. Description Part No. Mark No. Description Part No.
C1303-C1305,C1307-C1321 CKSRYF104Z16
C1323-C1336,C1403-C1405 CKSRYF104Z16
C1407-C1421,C1423-C1436,C1501 CKSRYF104Z16
C1503,C1601,C1603,C1701-C1710 CKSRYF104Z16
C1713,C1803-C1805 CKSRYF104Z16
RESISTORS
R1502,R1517,R1606,R1622 RAB4C101J
R1307,R1310-R1315,R1317,R1318 RAB4C220J
R1321,R1322,R1326-R1344,R1407 RAB4C220J
R1410-R1415,R1417,R1418 RAB4C220J
R1421,R1422,R1426-R1444 RAB4C220J
R1501,R1514,R1607,R1627,R1701 RAB4C470J
R1703-R1709,R1712-R1717 RAB4C470J
R1551,R1552 RS1/2S680J
Other Resistors RS1/16S
J
OTHERS
CN1701 50P CONNECTOR AKM1201
CN1501,CN1502,CN1504,CN1505 AKM1202
55P CONNECTOR
CN1601,CN1602,CN1604,CN1605 AKM1202
55P CONNECTOR
K1301,K1302,K1308,K1311-K1314 AKX9002
TEST PIN
K1316,K1321,K1324,K1326-K1331 AKX9002
TEST PIN
K1333,K1501,K1502,K1601,K1602 AKX9002
TEST PIN
K1728,K1729 TEST PIN AKX9002
X1801 CRYSTAL RESONATOR ASS1146
(50.000MHz)
CN1503,CN1603 PH CONNECTOR B8B-PH-SM3
CN1301 8P PLUG CKS3130
CN1702 30P CONNECTOR KF050HA30L
[D-D CONVERTER BLOCK]
SEMICONDUCTORS
Q1902,Q1905,Q1907 2SC2712
Q1903 DTC143EK
Q1901,Q1904,Q1906 HN1C01FU
D1903-D1906,D1911,D1912 1SS355
D1908 HZU2.2B
D1902,D1909 UDZ3.6B
D1907 UDZS5.1B
D1901 UDZS6.8B
CAPACITORS
C1904,C1906,C1912 CEV220M16
C1901-C1903,C1905,C1907-C1911 CKSRYF104Z16
RESISTORS
R1935,R1936 RS1/2S680J
Other Resistors RS1/16S J
OTHERS
K1901-K1906 TEST PIN AKX9002
1901 DC-DC CONVERTER AXY1054
CN1901 PH CONNECTOR B13B-PH-SM3
MR INTERFACE ASSY
[INTERFACE BLOCK]
SEMICONDUCTORS
IC4011 CXA1875AM
IC4007,IC4010 M5223AFP
IC4005 M62320FP
IC4001 PQ05DZ51
IC4002-IC4004 PQ20VZ1U
IC4013 PST9228N
IC4008,IC4009 TC74HC00AF
IC4012 TC74HC4066AF
IC4006 TC74VHCT541AFT
Q4003,Q4004,Q4010 2SA1162
Q4007,Q4009,Q4013,Q4017,Q4018 2SC2712
Q4012,Q4016,Q4019-Q4022 DTC124EK
Q4014 HN1A01FU
Q4008 HN1B04FU
Q4001,Q4002,Q4005,Q4006 HN1C01FU
Q4011,Q4015 RN2902
D4007,D4008 1SS184
D4002-D4006 1SS355
SWITCHES
S4001,S4004 ASH1010
CAPACITORS
C4023,C4036,C4037 CCSRCH102J50
C4025,C4032 CCSRCH220J50
C4029,C4030,C4053,C4054 CCSRCH471J50
C4001,C4004,C4005,C4008,C4010 CEAT101M10
C4012,C4013,C4016,C4041,C4042 CEAT101M10
C4034,C4038,C4050,C4056 CKSRYB105K6R3
C4043 CKSRYB474K10
C4027,C4028,C4033,C4051 CKSRYF103Z50
C4002,C4003,C4006,C4007 CKSRYF104Z16
C4014,C4015,C4017-C4019,C4024 CKSRYF104Z16
C4026,C4031,C4035,C4039,C4040 CKSRYF104Z16
C4044-C4047,C4049,C4052,C4055 CKSRYF104Z16
RESISTORS
R4019,R4035,R4054,R4066 RAB4C101J
R4056 RAB4C471J
R4007,R4014,R4015,R4117 RS1/16S1001F
R4106 RS1/16S1002F
R4107 RS1/16S1502F
R4098 RS1/16S2201F
R4078 RS1/16S2202F
R4074,R4094 RS1/16S3301F
R4075 RS1/16S4701F
R4057 RS1/16S5601F
R4124 RS1/16S5602F
R4004,R4005,R4115,R4116 RS1/16S8200F
R4093 RS1/16S8201F
R4006 RS2MMF2R2J
Other Resistors RS1/16S J
OTHERS
CN4004,CN4005 AKM1180
50P CONNECTOR
CN4002 20P SOCKET AKP1194
CN4003 24P DVI SOCKET AKP1216
CN4006,CN4009 B3B-PH-SM3
3P PH CONNECTOR
