Pioneer PDP-503PU User Manual

55
PDP-503PE, PDP-503PU
Mark No. Description Part No. Mark No. Description Part No.
CN4007 7P PH CONNECTOR B7B-PH-SM3
CN4008 8P PLUG CKS3130
[TMDS RECEIVER BLOCK]
SEMICONDUCTORS
IC4201 24LC01B
IC4203 24LC128(I)SN
IC4202 24LC32A
IC4205 PST9228N
IC4204 SII861CM208
Q4209,Q4212 2SA1162
Q4205,Q4206,Q4213 DTA124EK
Q4203,Q4204,Q4207,Q4208 DTC124EK
Q4210,Q4211,Q4214 DTC124EK
Q4201,Q4202 HN1C01FU
D4201 1SS184
D4203,D4204 1SS226
D4205-D4209 1SS355
D4202 RD6.8MB
FILTERS
F4201,F4203-F4205 EMI FILTER ATF1194
CAPACITORS
C4208,C4210,C4215,C4222,C4230 CCSRCH331J50
C4255,C4257 CCSRCH331J50
C4262 CCSRCH471J50
C4206,C4207,C4212,C4214,C4217 CCSRCH820J50
C4219,C4220,C4224,C4227,C4229 CCSRCH820J50
C4231-C4233,C4236,C4241,C4244 CCSRCH820J50
C4248,C4253,C4254,C4258 CCSRCH820J50
C4239,C4242,C4246,C4250 CEAT101M10
C4202,C4237,C4238 CEAT470M10
C4264 CKSRYB103K50
C4265 CKSRYB105K6R3
C4260 CKSRYB472K50
C4263 CKSRYB474K10
C4201,C4203-C4205,C4209,C4211 CKSRYF104Z16
C4213,C4216,C4218,C4221,C4225 CKSRYF104Z16
C4234,C4235,C4240,C4243,C4245 CKSRYF104Z16
C4247,C4251,C4252,C4256,C4259 CKSRYF104Z16
C4261 CKSRYF104Z16
C4223,C4226,C4228,C4249 CKSRYF105Z10
C4266-C4270 CKSRYF105Z10
RESISTORS
R4213-R4217,R4245,R4247 RAB4C181J
R4253-R4255 RAB4C181J
R4241 RAB4C680J
R4250 RS1/16S5100D
Other Resistors RS1/16S J
OTHERS
K4201-K4207 TEST PIN AKX9002
X4201 CRYSTAL RESONATOR ASS1163
(16.000MHz)
[AUDIO BLOCK]
SEMICONDUCTORS
Q4403 2SA1162
Q4401,Q4402 2SC2712
D4401-D4404 1SS355
CAPACITORS
C4408,C4417 CEANP100M50
C4403 CEAT101M10
C4407 CEAT101M25
C4402 CEAT220M50
C4425,C4426 CEAT470M25
C4410 CKSRYF104Z16
RESISTORS
All Resistors RS1/16S J
OTHERS
CN4403 7P PH CONNECTOR B7B-PH-SM3
CN4404 8P PH CONNECTOR B8B-PH-SM3
LED ASSY
SEMICONDUCTOR
D4751 AEL1170
OTHERS
CN4751 3P PH CONNECTOR S3B-PH-SM3
FRONT KEY ASSY
SWITCHES
S4801-S4806 ASG1088
CAPACITORS
C4801-C4803 CKSRYF104Z16
RESISTORS
All Resistors RS1/16S J
OTHERS
CN4801 6P FFC CONNECTOR AKM1208
FRONT KEY CONN ASSY
SEMICONDUCTORS
D4851,D4852 1SS226
OTHERS
CN4851 6P FFC CONNECTOR AKM1208
CN4852 4P PH CONNECTOR B4B-PH-SM3
IR (P) ASSY
SEMICONDUCTORS
Q4901 2SC2712
D4901 1SS355
