Pioneer PDP-503PU User Manual

56
PDP-503PE, PDP-503PU
Mark No. Description Part No. Mark No. Description Part No.
CAPACITORS
C4901 CEV470M6R3
C4902 CKSRYB103K50
C4903 CKSRYB472K50
C4904 CKSRYF104Z16
RESISTORS
All Resistors RS1/16S J
OTHERS
4901 REMOTE RECEIVER UNIT GP1UM26RK
THERMAL SENSOR ASSY
SEMICONDUCTORS
IC4702 LM50CIM3
IC4701 M5223AFP
CAPACITORS
C4705 CEV470M6R3
C4704 CKSRYB103K50
C4701 CKSRYF104Z16
C4702,C4703 CKSRYF105Z10
RESISTORS
R4706,R4708 RS1/16S3001F
Other Resistors RS1/16S J
AUDIO AMP ASSY
SEMICONDUCTORS
IC5202 CXA2021S
IC5002 LA4628
IC5201 NJM2193L
IC5001 PQ12RD1B
Q5002,Q5005 2SA1048
Q5009,Q5012,Q5013 2SC2458
COIL
L5001 FERRITE CORE ATX1037
CAPACITORS
C5203,C5227 CCCCH221J50
C5213,C5226 CEHANP220M25
C5232,C5233,C5235 CEHAT100M50
C5015,C5029,C5033,C5201,C5206 CEHAT101M25
C5242 CEHAT221M25
C5032,C5034 CEHAT2R2M50
C5044,C5050,C5051 CEHAT330M25
C5005 CEHAT331M16
C5238 CEHAT470M16
C5002 CEHAT471M16
C5013 CEHAT472M25
C5208,C5211,C5212,C5218 CEHAT4R7M50
C5222,C5223,C5234 CEHAT4R7M50
C5045 CEHATR47M50
C5014,C5204,C5217,C5220,C5228 CFTLA103J50
C5237 CFTLA103J50
C5035,C5046,C5053,C5056,C5216 CFTLA104J50
C5221,C5239 CFTLA104J50
C5214,C5230 CFTLA224J50
C5225 CFTLA333J50
C5219,C5236 CFTLA473J50
C5003,C5006,C5016,C5042,C5207 CKCYB103K50
C5210 CKCYB103K50
C5043,C5052,C5205,C5229 CQMA122J50
C5224 CQMA222J50
C5215,C5231 CQMA392J50
RESISTORS
R5053,R5054,R5075,R5076 RD1/2MMF2R2J
R5001 RD1/2MMF3R9J
Other Resistors RD1/4PU J
OTHERS
J5003 6P HOUSING WIRE ADX2729
J5002 8P HOUSING WIRE ADX2731
5006
FERRITE CORE HOLDER AEC1818
KN5001 GROUND PLATE ANK-142
5001,5002,5004,5005 SCREW VBB30P100FNI
SP TERMINAL ASSY
COILS
L5301,L5352 LINE FILTER ATF1206
CAPACITORS
C5301,C5305,C5351,C5355 CCCCH221J50
C5302,C5352 CKCYB332K50
C5303,C5353 CKCYF473Z50
RESISTORS
R5301,R5302,R5351,R5352 RD1/2MMF100J
OTHERS
CN5301 4P SPEAKER TERMINAL AKE1058
V MID CLAMP ASSY
SEMICONDUCTORS
Q9003,Q9004 2SA1162
Q9005,Q9006 2SB950A
Q9001,Q9002 2SC2712
D9001-D9008 1SS355
D9009,D9010 D1FL20U(S)
D9011,D9012 UDZ27B
CAPACITORS
C9001,C9002,C9005,C9006 ACG1101
(0.01µF/100V)
C9003,C9004 CKSRYF104Z16
RESISTORS
R9006 RS1/16S1002D
R9007-R9010 RS1/16S2202D
R9005 RS1/16S6801D
R9011-R9014 RT10PZ680K
Other Resistors RS1/16S J
OTHERS
9001 HEAT SINK L ANH1602
CN9001,CN9002 PH CONNECTOR B5B-PH-SM3
SCREW BBZ30P080FMC
