6.1.2 General Information of the Plasma Display and Media Receiver
Display example of the first page
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
CENTE
1/13
RVers
OSD V e r s i o n
CV I C V e r s i o n
TTXP Ve r s i on
ion
MON I T OR V e r s i o n
Mod e l S l eect inMa
Mod e l S l eectAV
Mod e l S l eect
Cen t e r cuAtime
MON I T OR
RESET
RESET OFF
RESET OFF
OFF
+
0
0
4
28
F6 91 10
TTX RPG
W2 0 0 /109 0 009:12/X200/109 0 079:12/V20
061
0/109 0 109:12/
MR O DS2 0109A//010
MR M IAN 0021E
-05
-00
PANEL V e r s i o n
FLASH Ve r s i on
MON I TOR Mo d e l
Mon i t o r Ac u t i me 4 7 H 4 2 M
H41M16
01
Pu l se Acu t ime 164
Sensore Temp
025H9//
NPIU S1GINoT
No. Item Explanation
1 Main software version information of the media receiver
2 OSD version information of the media receiver
3
IP/resize IC control software version information of the
media receiver
4
Text microcomputer software version information of the
media receiver
5
Module microcomputer software version information of the PDP
6 Panel microcomputer version information of the PDP
7 Panel flash ROM version information of the PDP
8 PDP model information
01: PIONEER 50 inches, 02: PIONEER 43 inches,
11: SHARP 50 inches, 12: SHARP 43 inches
9 Media receiver model information
10 Media receiver model information
11 PDP destination information
0: All SHARP destinations, Japanese and North America destinations of
PIONEER, 3: European and general destinations of PIONEER
12
Temperature information of panel temperature sensor on
the PDP
This is internal temperature information. This is not establishment
environment temperature.
13 Media receiver accumulation operating time
14 Media receiver accumulation operating time reset
Turn the display to [ON] by pressing the "VOL +" key, then it becomes [0H]
when pressing the "ENTER" key.
15 PDP accumulation operating time
16 PDP accumulation operating time reset
Turn the display to [ON] by pressing the "VOL +" key, then it becomes [0H]
when pressing the "ENTER" key.
17 PDP accumulation pulse number
Real accumulation pulse number becomes "indicated value *10,000,000 pulse".
Reference
18 PDP accumulation pulse number reset
Turn the display to [ON] by pressing the "VOL +" key, then it becomes [0]
when pressing the "ENTER" key.
∗ : Be careful so that there is the case that page constitution is different.
