PDP-503PE, PDP-503PU
93
No. Pin Name Function
101 P52 NC terminal
102 P53 NC terminal
103 AVCC 3.3V power supply
104 VREF A/D, D/A reference voltage input (unused)
105 STOPB The drive control input from IC1703 (PE5064)
106 P41 NC terminal
107 RYBY The flash memory note ready input
108 ADR_K_EMG_L1 The emergency input from panel bottom address resonance block
109 ADR_K_EMG_U1 The emergency input from panel upper address resonance block
110 ADR_K_EMG_L2 The emergency input from panel bottom address resonance block (unused)
111 ADR_K_EMG_U2 The emergency input from panel upper address resonance block (unused)
112 P47 NC terminal
113 AVSS GND
114 VSS GND
115 MUTE_ADR The panel mute signal input
116 MUTE_SUS The X and Y drive mute signal output (unused)
117 P15 NC terminal
118 HD The HD signal input from outside Assy (RGB Assy etc.)
119 P13 NC terminal
120 P12 NC terminal
121 PC_VIDEO The PC/Video identification output
122 VD The HD signal input from outside Assy (RGB Assy etc.)
123 MD0 The microcomputer mode of operation select signal input
124 MD1 The microcomputer mode of operation select signal input
125 MD2 The microcomputer mode of operation select signal input
126 PG0 NC terminal
127 CS_31Y IC1301, IC1401 (PD6358) control signal
128 CS_31X IC1301, IC1401 (PD6358) control signal
