PDP-504PU
21
5 678
56
7
8
C
D
F
A
B
E
FRONT PANEL SECTION Parts List
(2) CONTRAST TABLE
PDP-504PU/ TUCK, PDP-504PE/ WYVI6, PDP-504PE/ WYVI6XK and PRO-504PU/ KUC are constructed the
same except for the following :
2.8 PANEL CHASSIS (50) Assy (AWU1081)
PANEL CHASSIS (50) Assy (AWU1081) Parts List
2.9
PDP SERVICE Assy (AWU1080)
PDP SERVICE Assy (AWU1080) Parts List
Mark
No. Description Part No.
1PANEL LED Assy AWZ6787
2PANEL KEY Assy AWZ6788
3Panel Cushion V AED1199
4Panel Cushion H AED1226
5 Protect Panel Assy (50) See Contrast table (2)
NSP 6 Panel Holder (50) ANG2563
7 Cushion AEB1393
8Front Case Assy See Contrast table (2)
9Power Button See Contrast table (2)
10 Coil Spring ABH1114
11 Blind Cushion AEB1383
12 Screw BBZ30P050FMC
13 Screw ABZ30P060FMC
14 Serial Sheet AAX2609
15 Case Spacer S AEC1984
Mark No. Description Part No.
Mark No. Symbol and Description
PDP-504PU
TUCK
PDP-504PE
WYVI6
PDP-504PE
WYVI6XK
PRO-504PU
KUC
5 Protect Panel Assy (50) AMR3385 AMR3348 AMR3348 AMR3348
8Front Case Assy AMB2763 AMB2763 AMB2763 AMB2804
9Power Button AAD4123 AAD4123 AAD4123 AAD4126
Mark
No. Description Part No.
NSP 1..P. Chassis (50) Assy AWU1081
NSP 2..50 ADDRESS Assy AWV2069
NSP 3..50 ADDRESS Assy AWZ6839
NSP 2..50 SCAN FUKUGO Assy AWV2036
NSP 3..50 SCAN A Assy AWZ6809
NSP 3..50 SCAN B Assy AWZ6810
NSP 3..X CONNECTOR A Assy AWZ6811
NSP 3..X CONNECTOR B Assy AWZ6812
NSP 2..Address Module (IC1-IC40) AXF1116
NSP 2..Plasma Panel Assy(50")(V1)AAV1244
NSP 2..FPC (50XGA-X) ADY1084
NSP 2..FPC (50XGA-Y) ADY1085
NSP 2..Chassis Assy (50) ANA1774
2..PCB Spacer AEC1944
2..PCB Support AEC1958
2..Rivet (Plastic) AMR1066
2..FC Spacer AMR3370
2..Adhesive ZBA-KE3424G
NSP 2..Lotion ZLX-AP7
NSP 2..Tape ZTA-8101-12
NSP 2..Double Faced Tape ZTB-5015-18
NSP 2..Tape ZTC-POLYCA-11
NSP 2..Tape ZTC-POLYCA-20
NSP 2..Tape ZTC-900UL-15
NSP 2..Silicone Rubber ZTX-HC20-15
NSP 2..Wiping Cloth ZTX-MX100-13
NSP
2..Film
ZTX-2102Y35-2R5
NSP 2..Film ZTX-2102Y45-5
Mark
No. Description Part No.
Mark No. Description Part No.
NSP 1..P. Chassis (50) Assy AWU1081
NSP 2..Front Chassis H (50) ANA1733
2..Front Chassis VL (50) ANA1765
2..Front Chassis VR (50) ANA1766
2..Sub Frame L Assy ANG2559
2..Sub Frame R Assy ANG2561
2..Wire Saddle AEC1745
2..Clamp AEC1884
2..PCB Support AEC1938
2..PCB Spacer AEC1941
2..PCB Spacer AEC1947
2..Wire Clip AEC1948
2..Spacer AEB1397
2..Panel Cushion H (50) AED1226
2..Panel Cushion V (50) AED1199
2..Front Spacer AMR3369
2..Caution Label AAX3031
NSP 2..Drive Voltage Label ARW1097
2..Front Case (504 Service) AMB2811 (Note)
2..Rear Case (50P) ANE1614 (Note)
Note: The front case (504 Service) and rear case (50P) attached
to the Service Assy are for transportation only.
Do NOT use them as parts of the unit.
2..Screw AMZ30P060FZK
2..Screw AMZ30P080FMC
2..Screw AMZ30P080FZK
2..Screw PMB30P060FNI
2..Screw VBB30P080FNI
2..Screw ABZ30P100FZK
Mark
No. Description Part No.
To Next Page
