RESISTORS
R1631 (10,1/2W) ACN1174
R1632 RS1/16S1502F
R1633 RS1/16S1202F
Other Resistors RS1/16S###J
50 SCAN A ASSY
SEMICONDUCTORS
IC3001-IC3006 AN16003A-K
D3001 KU10N16
CAPACITORS
C3001,C3002,C3012,C3013 ACG1088
(0.1/250V)
C3023,C3024,C3034,C3035 ACG1088
(0.1/250V)
C3045,C3046,C3056,C3057 ACG1088
(0.1/250V)
C3005,C3008,C3016,C3019,C3026 CCSRCH101J50
C3029,C3037,C3040,C3048,C3051 CCSRCH101J50
C3060,C3063 CCSRCH101J50
C3004 CCSRCH151J50
C3007,C3018,C3033,C3044,C3050 CCSRCH181J50
C3062 CCSRCH181J50
C3006,C3011,C3017,C3022 CCSRCH331J50
C3031,C3032,C3042,C3043,C3049 CCSRCH331J50
C3055,C3061,C3066 CCSRCH331J50
C3009,C3010,C3020,C3021,C3028 CCSRCH390J50
C3030,C3039,C3041,C3053,C3054 CCSRCH390J50
C3064,C3065 CCSRCH390J50
C3003,C3014,C3025,C3036,C3047 CKSRYB105K6R3
C3058 CKSRYB105K6R3
RESISTORS
R3003,R3011,R3017,R3025,R3030 RAB4C221J
R3036 RAB4C221J
Other Resistors RS1/16S###J
OTHERS
CN3001 15P CONNECTOR AKP1218
K3001,K3004,K3009,K3015,K3017 AKX9002
TEST PIN
K3019,K3021 TEST PIN AKX9002
50 SCAN B ASSY
SEMICONDUCTORS
IC3201-IC3206 AN16003A-K
D3201 KU10N16
CAPACITORS
C3201,C3211,C3212,C3222,C3223 ACG1088
(0.1/250V)
C3233,C3234,C3244,C3245 ACG1088
(0.1/250V)
C3255,C3256,C3266 ACG1088
(0.1/250V)
C3203,C3204,C3214,C3215,C3226 CCSRCH101J50
C3228,C3237,C3239,C3247,C3251 CCSRCH101J50
C3258,C3259 CCSRCH101J50
C3258,C3259 CCSRCH101J50
C3262 CCSRCH151J50
Mark No. Description Part No.
C3261 CCSRCH181J50
C3205,C3210,C3216,C3221 CCSRCH331J50
C3230,C3231,C3241,C3242,C3248 CCSRCH331J50
C3254,C3260,C3265 CCSRCH331J50
C3208,C3209,C3219,C3220,C3227 CCSRCH390J50
C3229,C3238,C3240,C3252,C3253 CCSRCH390J50
C3263,C3264 CCSRCH390J50
C3202,C3213,C3224,C3235,C3246 CKSRYB105K6R3
C3257 CKSRYB105K6R3
RESISTORS
R3202,R3210,R3216,R3224,R3229 RAB4C221J
R3235 RAB4C221J
Other Resistors RS1/16S###J
OTHERS
CN3201 15P CONNECTOR AKP1218
K3203,K3208,K3214,K3216,K3218 AKX9002
TEST PIN
K3220,K3221 TEST PIN AKX9002
X CONNECTOR A ASSY
This assembly has no service part.
X CONNECTOR B ASSY
This assembly has no service part.
PANEL IF ASSY
[PANEL IF BLOCK]
SEMICONDUCTORS
IC4002 24LC02B(I)SN
>
IC4003 PQ033EZ01ZP
IC4006 TC74VHC541FT
Q4007 DTA143EUA
Q4004,Q4008,Q4009,Q4012 DTC143EUA
Q4014-Q4016 DTC143EUA
Q4005,Q4006,Q4010,Q4013,Q4017 RN1901
Q4011 RN2901
Q4001 SM6K2
D4006 1SS355
D4001-D4004,D4007 RB751V-40
>
D4005 UDZS5.1B
COILS AND FILTERS
F4001,F4002 ATF1194
L4001 LCTAW221J3225
CAPACITORS
C4005,C4006 CCSRCH100D50
C4019 CCSRCH101J50
C4009,C4020 CCSRCH471J50
C4011,C4018,C4021 CEAT101M10
C4003,C4015 CEAT101M16
C4004,C4010,C4012,C4014 CKSRYB103K50
C4016,C4024,C4041 CKSSYF104Z16
C4017 CKSRYF105Z10
RESISTORS
Mark No. Description Part No.
