Pioneer PDP-504PU User Manual

PDP-504PU
42
1234
1234
C
D
F
A
B
E
[MODULE UCOM BLOCK]
SEMICONDUCTORS
IC5206 24LC04B(I)SN
IC5201 M30626FHPGP-P
IC5205 PST3628UR
IC5208 TC74VHC08FT
IC5213 TC74VHC123AFT
IC5214,IC5215 TC74VHC32FT
IC5211,IC5212 TC74VHC541FT
IC5209 TC7W126FU
Q5201 2SJ461A
D5207-D5212 1SS301
D5217,D5218 1SS355
D5201 SML-310LT
SWITCHES AND RELAYS
S5201 ASH1047
CAPACITORS
C5213,C5225 (47/6.3V) ACH1357
C5206,C5223,C5231 CKSRYB102K50
C5245-C5264 CKSRYB102K50
C5232 CKSRYB104K16
C5230 CKSRYB105K6R3
C5205 CKSRYB472K50
C5201-C5204,C5208,C5210-C5212 CKSSYF104Z16
C5218,C5224,C5226,C5227 CKSSYF104Z16
C5243,C5244 CKSSYF104Z16
RESISTORS
R5209,R5211,R5212,R5235 RAB4C101J
R5254,R5255,R5265,R5266 RAB4C101J
R5205 RAB4C103J
R5270,R5271 RAB4C472J
R5256,R5257 RAB4C474J
Other Resistors RS1/16S###J
OTHERS
CN5201 PLUG 8-P AKM1225
K5201 TEST PIN AKX9002
>
X5201 CERAMIC RESONATOR ASS1178
CN5202 3P PH CONNECTOR B3B-PH-SM3
[PANEL FLASH BLOCK]
SEMICONDUCTORS
IC5305 MBM29PL160BD-75PTFN
IC5303 PST3612UR
IC5301 PST3628UR
IC5302 TC74VHC08FT
Q5301 RN1901
D5301-D5310 1SS302
CAPACITORS
C5320 CCSRCH470J50
C5304,C5307 CKSRYB102K50
C5311,C5314 CKSRYB104K16
C5303,C5306 CKSRYB472K50
C5301,C5302,C5305,C5309,C5313 CKSSYF104Z16
C5316 CKSSYF104Z16
RESISTORS
R5317,R5318 RAB4C101J
Other Resistors RS1/16S###J
Mark No. Description Part No.
OTHERS
CN5301 PLUG 15-P AKM1232
K5301 TEST PIN AKX9002
>
X5302 CRYSTAL OSCILLATOR ASS1174
>
X5301 CRYSTAL OSCILLATOR ASS1176
[IC4 BLOCK]
SEMICONDUCTORS
IC5401 PD5856A
D5401 SML-310LT
D5402 SML-310MT
COILS AND FILTERS
F5401,F5403,F5409,F5410 ATF1194
CAPACITORS
C5401,C5413,C5417,C5424 ACH1396
(100/6.3V)
C5434,C5435 CKSRYB102K50
C5402-C5412,C5414-C5416 CKSSYF104Z16
C5418-C5423,C5425-C5431 CKSSYF104Z16
RESISTORS
R5406,R5421 RAB4C101J
R5408-R5413,R5415,R5416,R5419 RAB4C220J
R5422 RAB4C220J
R5405 RS1/16S5601F
Other Resistors RS1/16S###J
OTHERS
K5401 TEST PIN AKX9002
[ADDRESS CN BLOCK]
RESISTORS
Other Resistors RS1/16S###J
OTHERS
CN5521 50P CONNECTOR AKM1201
>
CN5501-CN5508 40P CONNECTOR AKM1217
CN5511 30P FFC CONNECTOR AKM1218
[DIGITAL DD CON BLOCK]
SEMICONDUCTORS
>
IC5602 PQ05DZ11
>
IC5603 PQ09DZ11
>
U5601 AXY1066
Q5601,Q5603 HN1C01FU
Q5605 RN1901
D5602,D5603,D5609,D5610 1SS355
D5601 HZU2.2B
D5604 UDZS5.1B
CAPACITORS
C5601,C5603,C5607,C5614,C5616 ACH1394
(100/16V)
C5602,C5604,C5615,C5617 CKSRYB103K50
C5605,C5606,C5610 CKSSYF104Z16
RESISTORS
R5601 (1,1/2W) ACN1162
R5627 (3.3,1/2W) ACN1168
Other Resistors RS1/16S###J
Mark No. Description Part No.
