Pioneer PDP-504PU User Manual

PDP-504PU
44
1234
1234
C
D
F
A
B
E
RESISTORS
R1154 RD1/4PU390J
R1116,R1122 RS1/10S1003F
R1133,R1143-R1145 RS1/10S100J
R1103,R1106,R1110,R1111,R1118 RS1/10S2R2J
R1119,R1153,R1123,R1126 RS1/10S2R2J
R1136 RS1/16S1202F
R1139 RS1/16S3301F
R1130 RS1/16S5601F
R1134 RS1/16S8201F
R1113,R1128 RS1MMF101J
VR1101-VR1104 CCP1390
Other Resistors RS1/16S###J
[50 X SUS BLOCK]
SEMICONDUCTORS
IC1202 HCPL-M611
IC1205 NJM2872F05
IC1203,IC1207 STK795-512
IC1208 TLP181(P-GR)
IC1204,IC1206 TND301S
Q1207 2SC2412K
Q1203 2SD1898
Q1302 2SJ522
Q1301 2SK2503
Q1205 2SK3116-Z
Q1206,Q1208 DTC124EK
Q1201 HN1B04FU
D1212 1SS302
D1211,D1213,D1216 1SS355
D1201,D1207 EC10QS04
D1204,D1301 EC11FS4
D1214 EC8FS6
D1208 UDZS5.6B
COILS AND FILTERS
L1204,L1205 ATH1112
L1202 LFEA100J
L1203,L1206 LFEA470J
CAPACITORS
C1214-C1217,C1227-C1230 ACE1163
C1233 (0.12/250V) ACE1169
C1244 (0.1/250V) ACE1170
C1209 (0.1/630V) ACG1092
C1219,C1231 ACH1358
C1224 CEHAT101M16
C1301 CEHAT221M25
C1203,C1207,C1210,C1220,C1223 CEHAT470M25
C1238,C1239 CEHAT470M25
C1235 CKSRYB102K50
C1213,C1225,C1240,C1241,C1243 CKSRYB104K16
C1202,C1205,C1206,C1212,C1302 CKSRYF104Z50
RESISTORS
R1230 (2.2, 1/2W) ACN1166
R1208,R1321,R1322 (10,1/2W) ACN1174
R1304 (560,1/2W) ACN1195
R1305 (1k,1/2W) ACN1198
R1301,R1302,R1314 RS1/10S122J
R1226,R1251 RS1MMF331J
Mark No. Description Part No.
R1235,R1236 RS2MMF121J
Other Resistors RS1/16S###J
OTHERS
KN1201-KN1205,KN1208,KN1209 ANK-142
(GROUND PLATE)
KN1210-KN1212,KN1213,KN1214 ANK-142
(GROUND PLATE)
CN1201 12P CONNECTOR B12B-EH
[50 X D-D CON BLOCK]
SEMICONDUCTORS
IC1404 AN1431M
IC1402 MIP161
IC1401,IC1403 TLP181(P-GR)
Q1401 2SA1037K
Q1402 2SC2412K
D1407,D1408 EC11FS2
D1404 EC8FS6
D1401,D1403 UDZS5.6B
COILS AND FILTERS
L1401 ATH1110
T1401 ATK1153
CAPACITORS
C1401,C1402 (22/315V) ACH1361
C1404 CEHAT101M16
C1405 CEHAT101M25
C1409 CEHAT331M16
C1403,C1407,C1408,C1411 CKSRYB104K16
C1406 CKSRYF104Z50
RESISTORS
R1405,R1406,R1408-R1410,R1414 RS1/10S3602F
R1420 RS1/16S1101F
R1403 RS1/16S2702F
R1401,R1404 RS1/16S4701F
R1417 RS1/16S7500F
VR1401 (1k) CCP1390
Other Resistors RS1/16S###J
OTHERS
1002 CARD SPACER AEC1957
1001 DRIVE SIRICON SHEET A AEH1062
1001 PLATE X ANG2622
1001 DRIVE HEATSINK A ANH1613
1001 SCREW BMZ30P080FZK
1002 SCREW PMB30P060FNI
PANEL SENSOR ASSY
SEMICONDUCTORS
IC1072 MM1522XU
IC1071 MM3012XN
CAPACITORS
C1075 (47/6.3V) ACH1357
C1074 CKSRYB103K50
C1071,C1076 CKSRYB104K16
C1072,C1073 CKSRYF105Z10
Mark No. Description Part No.
