PDP-504PU
46
1234
1234
C
D
F
A
B
E
C2341 CKSRYB104K16
C2301,C2307,C2328 CKSRYF104Z50
RESISTORS
R2332 (2.2,1/2W) ACN1166
R2364,R2365 (10,1/2W) ACN1174
R2309 RS1MMF132J
R2310,R2311 RS1MMF472J
R2312-R2314,R2322,R2323 RS3LMF100J
R2348,R2352,R2358,R2359 RS3LMF1R8J
Other Resistors RS1/16S###J
OTHERS
KN2301-KN2305,KN2310,KN2311 ANK-142
(GROUND PLATE)
KN2312,KN2314,KN2315,KN2316 ANK-142
(GROUND PLATE)
CN2301 11P CONNECTOR B11B-EH
[50 Y SCAN BLOCK]
SEMICONDUCTORS
IC2101,IC2103-IC2106 HCPL-M611
IC2108,IC2109 HCPL-M611
IC2102,IC2107 TC74ACT540FT
COILS AND FILTERS
L2101-L2103 LFEA100J
CAPACITORS
C2104,C2111,C2116,C2117 (47/160V) ACH1392
C2101,C2107,C2113 CEHAT221M16
C2102,C2103,C2105,C2106 CKSRYB104K16
C2108-C2110,C2112,C2114 CKSRYB104K16
RESISTORS
R2121,R2128 RAB4C472J
Other Resistors RS1/16S###J
OTHERS
CN2101,CN2102 15P CONNECTOR AKM1200
[50 Y D-D CON BLOCK]
SEMICONDUCTORS
IC2410-IC2412 AN1431M
IC2406 BA10358F
IC2401 MIP0223SC
IC2402-IC2405,IC2407-IC2409 TLP181(P-GR)
Q2402,Q2407 2SA1037K
Q2410 2SA1163
Q2417 2SA1535
Q2411-Q2414,Q2416 2SC2412K
Q2405 2SC2713
Q2403 2SD1664
Q2401,Q2404 2SD1898
Q2415 HN1C01FU
D2430 1SS301
D2410,D2419,D2436 1SS302
D2409,D2418 1SS355
D2404-D2407 EC11FS2
Mark No. Description Part No.
D2403,D2414 EC11FS4
D2402 EC8FS6
D2427 RD91PA
D2401 U1ZB330
D2412, D2413, D2422 UDZS15B
D2425,D2426 UDZS27B
D2415 UDZS33B
D2432 UDZS4.3B
D2423,D2431 UDZS5.6B
COILS AND FILTERS
T2402 ATK1156
T2403 ATK1157
T2401 ATK1158
L2402 LFEA100J
L2401 LFEA101J
L2403 LFEA470J
CAPACITORS
C2406 (100/160V) ACH1360
C2401 (22/315V) ACH1361
C2427 CEHAT100M50
C2403 CEHAT101M16
C2405,C2407,C2417 CEHAT101M25
C2414 CEHAT221M16
C2410 CEHAT221M25
C2411 CEHAT331M25
C2420 CEHAT470M2A
C2409,C2419 CKSRYB103K50
C2402,C2412,C2413,C2423,C2425 CKSRYB104K16
C2431,C2432,C2434-C2436 CKSRYB104K16
C2441-C2443 CKSRYB104K16
C2415,C2421,C2428 CKSRYB105K6R3
C2404,C2408,C2416,C2418,C2426 CKSRYF104Z50
C2429 CKSRYF104Z50
RESISTORS
R2429 (180k,1/2W) ACN1225
R2435,R2439 RS1/10S2202F
R2402-R2404 RS1/10S3902F
R2442 RS1/16S1201F
R2468 RS1/16S1202F
R2424 RS1/16S2001F
R2420,R2427,R2438 RS1/16S2201F
R2467 RS1/16S3301F
R2457-R2460 RS1/16S4701F
R2506 RS3LMF151J
VR2401,VR2402 (1k) CCP1390
Other Resistors RS1/16S###J
OTHERS
2401 HEATSINK ANH1614
2401 SCREW BBZ30P080FZK
Mark No. Description Part No.
