Pioneer PDP-504PU User Manual

PDP-504PU
9
5 678
56
7
8
C
D
F
A
B
E
PACKING Parts List
(2) CONTRAST TABLE
PDP-504PU/ TUCK, PDP-504PE/ WYVI6, PDP-504PE/ WYVI6XK and PRO-504PU/ KUC are constructed the
same except for the following :
Mark
No. Description Part No.
>
1Power Cord See Contrast table (2)
>
2Power Cord See Contrast table (2)
3 Wiping Cloth AED1208
4 Binder Assy AEC1908
5 Code Case See Contrast table (2)
6 Center Pad (50) AHA2335
NSP 7 Warranty Card See Contrast table (2)
8 Mirror Mat See Contrast table (2)
9Pad (PP T- L) AHA2315
10 Pad (PP T- R) AHA2316
11 Pad (PP B- L) AHA2343
12 Pad (PP B- R) AHA2344
13 Carton (50) See Contrast table (2)
14 Upper Carton (50) See Contrast table (2)
15 Vinyl Bag AHG1310
16 Caution Card ARM1232
17 Speaker Cushion See Contrast table (2)
18 Vinyl Bag S See Contrast table (2)
19 Ferrite Core See Contrast table (2)
20 Inner Carton See Contrast table (2)
21 Polyethirene Sheet See Contrast table (2)
22 Paper See Contrast table (2)
23 Sub Carton See Contrast table (2)
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-504PU
TUCK
PDP-504PE
WYVI6
PDP-504PE
WYVI6XK
PRO-504PU
KUC
>
1Power Cord ADG1215 Not used Not used ADG1215
> 2Power Cord Not used ADG1214 ADG1214 Not used
5 Code Case AHC1041 AHC1041 AHC1049 Not used
NSP 7 Warranty Card ARY1138 ARY1114 ARY1114 ARY1134
8 Mirror Mat AHG1284 AHG1284 AHG1327 AHG1284
13 Carton (50) AHD3177 AHD3177 Not used Not used
13 Carton (50) Not used Not used AHD3191 Not used
13 Carton (50EL) Not used Not used Not used AHD3222
14 Upper Carton (50PU) AHD3178 Not used Not used Not used
14 Upper Carton (504PE) Not used AHD3203 Not used Not used
14 Upper Carton (50) Not used Not used AHD3190 Not used
14 Upper Carton (50EL) Not used Not used Not used AHD3223
17 Speaker Cushion AEB1384 AEB1384 AEB1384 Not used
18 Vinyl Bag S AHG1338 AHG1338 Not used AHG1338
19 Ferrite Core Not used ATX1039 ATX1039 Not used
20 Inner Carton Not used Not used Not used AHB1251
21 Polyethirene Sheet Not used Not used Not used AHG1341
22 Paper Not used Not used Not used AHG1343
23 Sub Carton AHB1248 AHB1248 AHB1248 Not used
